MODEL TCM-3500Z-2 0109-001 150 㧸ࠦࡦࡌࠕㇱ L CONVEYOR SECTION Fig. 7-1 ࠦࡦࡌࠕ Conveyor D C B A D A B 2 0 18 18 1 7 14 14 42 42 43 43 44 44 53-3 53 53 4 7 4 8 46 46 28 28 29 29 3 0 9 6 2 7 1 5 1 6 67 67 6 8 6 6 6 9 1 1 12 12 13 …
MODEL TCM-3500Z-2
0109-001
149
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
111 630 076 1917 ASSY,CORD (C35-Y-COAD) 1
113 630 076 1924 ASSY,CORD (C35-XL-1) 1
114 630 076 1931 ASSY,CORD (C35-XL-2) 1
115 630 076 1955 ASSY,CORD (C35-XR-1) 1
116 630 076 1894 ASSY,CORD (C35-ABLA-1) 1
117 630 076 1900 ASSY,CORD (C35-ABLA-2) 1
126 630 076 1962 ASSY,CORD (C35-NCN11-12) 1
6-10
MODEL TCM-3500Z-2
0109-001
150
㧸ࠦࡦࡌࠕㇱ L CONVEYOR SECTION
Fig. 7-1 ࠦࡦࡌࠕ Conveyor
D
C
B
A
D
A
B
20
18
18
17
14
14
42
42
43
43
44
44
53-3
53
53
47
48
46
46
28
28
29
29
30
96
27
15
16
67
67
68
66
69
11
12
12
13
13
45
45
52
52
51
51
50
49
49
53-1
53
28
29
30
27
27
38
53
53-1
53-1
18
18
19
36
35
34
34
37
33
33
3
53-3
53-2
53
53
26
25
39
39
40
41
55
55
53
53-3
53-3
42
46
31
32
48
48
53
53-2
49
49
50
51
52
31
32
32
39
45
45
14
15
16
16
40
40
41
91
91
92
92
93
93
47
4
5
6
2
E
F
34
35
36
36
37
33
24
24
23
22
22
26-1
54
54
53
53-3
53-3
60-1
59
58
56
8
53-3
53-3
53
38
38
9
10
10
7
60
59
58
43
44
53
43
44
53
53
CCCC
2121
21
76
76
74
74
73
73
71
71
72
72
75
75
79
79
78
78
77
77
74
72
73
75
76
79
78
77
71
E
F
53-3
53-3
53
53
53-3
53-3
55
60
60
59
59
58
58
57
57
8-1
54
53-353-3
Fig.7-1
TCM-3500Z-2
MODEL TCM-3500Z-2
0109-001
151
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
7-1
2 630 064 8119 BASE(CONVEYOR L) 1 678G--02B-001
3 630 053 0629 PLATE 1 678G--02B-004
4 411 141 4107 WASHER V 5X10X1 2 FW5
5 411 141 6705 WASHER SPR 5 2 SW5
6 630 000 7749 BOLT,HEX-SCT 2 M5X10
7 630 001 1548 BEARING,RADIAL 2 678G--02H-022
8 630 064 8164 PLATE(MAE) 1 678G--02B-012
8 -1 630 070 3443 PLATE (OKU) 1 678G--02B-011
9 630 064 8126 PLATE,LOCATE(L) 1 678G--02B-003
10 630 053 0612 PLATE,LOCATE 1 678G--02B-006
11 411 141 4107 WASHER V 5X10X1 2 FW5
12 411 141 6705 WASHER SPR 5 2 SW5
13 630 000 7749 BOLT,HEX-SCT 2 M5X10
14 411 141 4305 WASHER V 6X12.5X1.6 6 FW6
15 411 141 3001 WASHER SPR 6 6 SW6
16 630 000 7886 BOLT,HEX-SCT 6 M6X16
17 630 030 5913 COLLAR 2 678G--02B-007
18 630 001 1531 BEARING,RADIAL 4 678G--02H-021
19 630 065 4264 GUIDE,SLIDE 2 678G--02H-024
20 411 000 7805 RING C 20 2 678G--02H-023
21 630 000 8883 SET SCREW 2 M3X4 SET
22 630 008 5303 BEARING,UNIT 2 678G--02H-020
23 411 141 4305 WASHER V 6X12.5X1.6 4 FW6
24 411 141 3001 WASHER SPR 6 4 SW6
25 630 000 7879 BOLT,HEX-SCT 4 M6X12
26 630 000 8920 SET SCREW 2 M4X6 SET
26 -1 630 053 5419 COLLAR 2 678G--02B-025
27 630 065 4295 BALL SCREW 2 678G--02H-010
28 411 141 4008 WASHER V 4X9X0.8 8 FW4
29 411 141 2905 WASHER SPR 4 8 SW4
30 630 000 7657 BOLT,HEX-SCT 8 M4X16
31 630 001 1432 BEARING,RADIAL 2 678G--02H-009
32 411 000 7300 RING C 12 2 678G--02H-004
33 630 031 0566 BEARING,UNIT 2 678G--02H-012
34 411 141 4305 WASHER V 6X12.5X1.6 4 FW6
35 411 141 3001 WASHER SPR 6 4 SW6
36 630 000 7879 BOLT,HEX-SCT 4 M6X12
37 630 031 0573 NUT 2 678G--02H-013
38 630 064 8133 STAY 2 678G--02B-008
39 411 141 4305 WASHER V 6X12.5X1.6 4 FW6
40 411 141 3001 WASHER SPR 6 4 SW6
41 630 000 7886 BOLT,HEX-SCT 4 M6X16
42 630 053 0636 PLATE 4 678G--02B-005
43 630 001 0220 WASHER 4 678G--02H-027
44 630 000 7763 BOLT,HEX-SCT 4 M5X16
45 411 141 0505 NUT HEX 5 4 M5
46 411 118 8503 NUT HEX 5 4 M5 F
47 411 140 6508 SCR PAN 5X20 4 M5X20 PAN
48 630 002 9697 SPRING,TENSION 4 678G--02H-003
49 630 055 2928 SPACER(BRG) 2 678G--02B-030
