G -S063-07
0709-001
6
搬送部全体
OVERALL
TRANSFER SECTION
Fig. N-1
バックアップベース
Back-up Base
8
7
7
6
36
34
34
17
15
17
15
1
32
33
39
40
28
21
22
23
3
27
27
93
.
55
.
56
12
13
14
44
44
44
35
42
44
18
47
47
50
50
50
48
50
50
50
6
7
7
44
8
36
34
35
1
32
33
40
28
21
23
22
39
39
39
34
75
.
53
.
54
78
78
78
78
74
.
53
.
54
95
9
86
.
64
.
65
94
.
55
.
56
96
.
60
.
61
89
.
67
.
68
93
.
55
.
56
89
.
67
.
68
96
.
60
.
61
95
86
.
64
.
65
86
.
64
.
65
74
.
53
.
54
75
.
53
.
54
94
.
55
.
56
12
14
13
75
.
53
.
54
43
89
.
67
.
68
9
92
.
67
.
68
92
.
67
.
68
9
44
44
92
.
67
.
68
92
.
67
.
68
92
.
67
.
68
89
.
67
.
68
44
18
42
47
48
47
75
.
53
.
54
43
内が大基板対応箇所です。
Inside the box shows the Large PCB applicable section.
7
G -S063-07
1004-003
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
1 6301683331 FRAME 2 866N--100-001 210B4355
3 6301164915 PIPE FITTINGS 2 866N--100-523 225F0504
6 6301616445 HOLDER 2 866N--100-601 216B1770
7 6301616452 HOLDER 4 866N--100-602 216B1771
8 6301587189 STAY 16 866N--100-608 211J1514
9 6301572222 BOLT,HEX-SCT 20 866N--100-609 221A0430
12 6301333106 VALVE 2
866N-A100020-A002
225C0125
13 6301106083 PIPE FITTINGS 2
866N-A100020-A003
225F0467
14 6300036534 AIR LINE EQPT 4
866N-A100020-A004
225B0059
15 6300482935 AIR LINE EQPT 4
866N-A100020-A005
225B0251
17 6301164915 PIPE FITTINGS 2
866N-A100020-A007
225F0504
18 6300034301 GREASE NIPPLE 6 866N--100-018 226B0002
21 6301333106 VALVE 2 Y0842 866N--100-501 225C0125
22 6301268064 PIPE FITTINGS 2 866N--100-502 225F0577
23 6300036534 AIR LINE EQPT 4 866N--100-503 225B0059
27 6301545820 SENSOR,PHOTO 2 B5501,B5601
866N--100-027 23G10096
28 6300000269 SENSOR,PHOTO(CONNECTOR) 2 866N--100-028 23G10003
32 6301554914 VALVE 2 Y0834,Y0835
866N--100-032 225C0160
33 6301554907 VALVE 2 Y0836 866N--100-033 225C0159
34 6300482935 AIR LINE EQPT 8 866N--100-034 225B0251
35 6300955026 AIR LINE EQPT 2 866N--100-035 225B0367
36 6301587240 BRACKET 2 866N--100-236 211FC655
39 6301256450 GUIDE,LINEAR 4 866N--100-039 222L0690
40 6300000245 SENSOR,PHOTO 2 B5301 866N--100-040 23G10001
42 6301580654 BLOCK 2 866N--100-722 211G5388
43 6301325477 ACCESSORY,P.C.B 4
866N-A100020-A013
23L10096
44 6301250212 PIPE FITTINGS 12 866N--100-724 225F0566
47 6301596648 TUBE 4 866N--100-727 225G0347
48 6301596655 TUBE 2 866N--100-728 225G0348
50 6301596969 BOX 6 866N--100-730 211B1327
53 4111412806 WASHER SPR 3 12 866N--100-803 221H0281
54 4111413902 WASHER V 3X7X0.5 12 866N--100-804 221H0312
55 4110864408 WASHER SPR 3 8 866N--100-805 221H0280
56 4110889005 WASHER F 3X6X0.5 8 866N--100-806 221H0337
60 4110081706 WASHER SPR 4 2 866N--100-810 221H0283
61 4111192104 WASHER V 4X9X0.8 2 866N--100-811 221H0314
64 4111416705 WASHER SPR 5 18 866N--100-814 221H0287
65 4111414107 WASHER V 5X10X1 18 866N--100-815 221H0318
67 4111413001 WASHER SPR 6 30 866N--100-817 221H0289
68 4111414305 WASHER V 6X12.5X1.6 30 866N--100-818 221H0320
74 6300007510 BOLT,HEX-SCT 8 4 M3X8 866N--100-824 221A0006
75 6300007565 BOLT,HEX-SCT 4 8 M3X20 866N--100-825 221A0011
78 6300007633 BOLT,HEX-SCT 40 M4X12 866N--100-828 221A0018
SL-G300
G -S063-07
N-1
8
G -S063-07
1004-003
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
86 6300007763 BOLT,HEX-SCT 18 M5X16 866N--100-836 221A0031
89 6300007909 BOLT,HEX-SCT 18 M6X25 866N--100-839 221A0045
92 6300007862 BOLT,HEX-SCT 12 M6X10 866N--100-842 221A0041
93 4110406202 SCR PAN 3X10 4 866N--100-903 221E0488
94 4110407803 SCR PAN 3X12 4 866N--100-904 221E0489
95 4110435004 SCR PAN 4X8 4 866N--100-905 221E0510
96 4111621505 SCR PAN 4X20 2 866N--100-906 221E0504
