DT401-F - 第23页
Ref No. Remark s R 1 Q'ty 1-D 本体部 Mai n B od y ｲﾗｽﾄ No. Part No. 品 名 品番 数量 R 2 パーツリスト Kit N o . キット 品 番 Kit Name キット名称 KXFX03KEA00 Part Nam e 備 考 ｾｸｼｮﾝN o. PARTS LIST Section No. R 3 BRACKET 1 1 N210140516AA BRACKET…
1-D
本体部
Main Body
パーツレイアウト
Kit No.
キット品
番
Kit Name
キット名称
KXFX03KEA00
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M7
( KKXFX03KEA00-50-4 )
Ref
No.
Remarks
R
1
Q'ty
1-D
本体部
Main Body
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
KXFX03KEA00
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
BRACKET
1
1 N210140516AA
BRACKET
1
2 N210140517AA
BRACKET
2
3 N210140519AA
COVER
1
4 N210018328AA
COVER
1
5 N210018305AA
BRACKET
4
6 KXFB02T8A00
BRACKET
1
7 KXFB03RQA00
BRACKET
1
8 KXFB0556A00
BRACKET
1
9 KXFB0557B00
BRACKET
1
10 KXFB02GVA00
BRACKET
1
11 KXFB02NPA00
BRACKET
2
13 KXF0DT6AA00 HCBV5
MAGNET
4
14 KXF01EXAA00 C-54-2
BRACKET
4
15 KXF0DX10A00 HCBV8
JOINT
1
17 KXF09MKAA00 KQE06-02
GAUGE
1
18 KXF0E1H0A00 GZ46-K-02
REGULATOR
1
19 N510058650AA ARP30-02H-RY-X2116
REGULATOR
2
20 N610034312AA
REGULATOR
1
21 KXFX061GA00
REGULATOR
1
22 N610034318AA
REGULATOR
1
23 KXF0E4LFA00 AR20-02B-1R-X2118
GAUGE
2
24 KXF0DR7AA00 G36-2-01
JOINT
1
25 KXF02C9AA00 KQL08-02S
JOINT
2
26 KXF02ATAA00 KQH04-01S
TUBE
5
27 KXF0DRAAA00 TU0425B
JOINT
5
28 KXF0CS5AA00 KQE04-01
JOINT
1
29 KXF0CS0AA00 KQZD06-02S
GAUGE
1
30 KXF073QAA00 G36-10-01
JOINT
1
31 KXF02CKAA00 KQL12-02S
JOINT
1
32 KXF0CS3AA00 KQZD08-02S
PLUG
2
33 KXF02TGAA00 M-5P
GAUGE
2
34 KXF0DRCAA00 G36-7-01
JOINT
4
35 KXF02C3AA00 KQL06-M5
JOINT
2
36 KXF02AWAA00 KQH04-M5
JOINT
1
37 KXF02BZAA00 KQL06-02S
JOINT
1
38 KXF07FYAA00 KQLU06-02S
JOINT
1
39 KXF02BPAA00 KQL04-01S
BRACKET
1
40 N420B320 B320
BRACKET
1
41 N210050412AB
COVER
1
42 N210053432AB
BOLT
2
43 N510017776AA
Hexagon head bolt Best class M8X20-6g 4T A2J (Trivalent)
TRIM
1
44 KXF0DUUAA00 CE-016
TRIM
2
45 KXF0DUUAA00 CE-016
M8
--
( KKXFX03KEA00-50-4 )
1-E
本体部
Main Body
パーツレイアウト
Kit No.
キット品
番
Kit Name
キット名称
KXFX03KEA00
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M9
( KKXFX03KEA00-50-5 )
