DT401-F - 第276页
40- J デュアルコンベア Dual Conveyor パーツレイアウト Ki t N o . キット 品番 Kit N am e キット名称 N610001652AA ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - S151 ( KN610001652AA-20-10 )
Ref
No.
Remarks
R
1
Q'ty
40-I
デュアルコンベア
Dual Conveyor
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610001652AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
BLOCK
2
1 N210003511AA
BLOCK
1
2 N210003512AA
GUIDE
1
3 N210003574AA
BRACKET
1
4 N210003590AA
BRACKET
1
5 N210003592AA
BRACKET
1
6 N210003602AA
BRACKET
1
7 N210003604AA
GUIDE
1
8 N210003606AA
GUIDE
1
9 N210006377AA
VALVE
1
10 KXF09X2AA00 VQZ1121-5MO-C4
JOINT
3
11 KXF029JAA00 KJL04-M5
SPEED-CONTROLLER
2
12 KXF05BGAA00 AS1301F-M5-06
SPEED-CONTROLLER
2
13 KXF0DZ1BA00 AS1200-M5
JOINT
2
14 KXF0DY7YA00 KQR23-04
JOINT
2
15 KXF0CT5AA00 KQVF04-M5
JOINT
4
16 KXF02AWAA00 KQH04-M5
JOINT
2
17 KXF08KDAA00 KJU04-M5
JOINT
4
18 N431KQVF06M5 KQVF06-M5
SPACER
4
19 KXF0A8QAA00 ASF-520
JOINT
10
20 KXF07TFAA00 M-5ALU-3
JOINT
10
21 KXF02SZAA00 M-5ALU-4
JOINT
2
22 KXF02B4AA00 KQH06-M5
GASKET
1
23 KXF09Y6AA00 VQZ1000-GS-2
GROMMET
1
24 N510058980AA C-30-BW-19-1-EP-UL
JOINT
4
25 KXF02DLAA00 KQU04-06
S150
--
( KN610001652AA-20-9 )
40-J
デュアルコンベア
Dual Conveyor
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610001652AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
S151
( KN610001652AA-20-10 )
Ref
No.
Remarks
R
1
Q'ty
40-J
デュアルコンベア
Dual Conveyor
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610001652AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
GUIDE
8
1 N210007883AA
BLOCK
2
2 KXFB04V0A00
GUIDE
4
3 N210008462AA
CLAMPER
4
4 N210003488AB
BLOCK
16
5 N210008094AA
BLOCK
8
6 N210008253AA
NUT
16
7 KXFB04VHA00
BLOCK
8
8 N210008257AA
PLATE
16
9 N210003529AA
LINEAR-WAY
16
10 KXF0DY7TA00 MGN7HE1R40Z0HM(DDA)
BOLT
64
11 XVE2B3FTC Hexagon socket head cap screw M2X3-12.9 SOB
WASHER
16
12 KXF0CSSAA00 WSSB8-3-1
BOLT
48
13 XVE2B6FTC Hexagon socket head cap screw M2X6-12.9 SOB
SPACER
4
14 KXF0BMZAA00 ASF-508
JOINT
2
15 N510064397AA M-3ALU-3-X83
JOINT
64
16 N510064399AA M-3AU-3-X83
JOINT
2
17 KXF0937AA00 M-5AU-3
JOINT
4
18 KXF02TLAA00 M-5UT
JOINT
6
19 KXF0DV8AA00 KJU23-M5
CYLINDER
16
20 KXF0DY82A00 CUJB8D-W8095-5(DDA)
GASKET
8
21 N510038461AA M-5G2
WASHER
4
22 N560WSSB851 WSSB8-5-1
S152
--
( KN610001652AA-20-10 )
