Mycronic has always made it easy to transition from

volume production to small test batches or proto-

types. No re-programming, no re-tooling and no

reconﬁ guring of vision camera parameters. Sim-

ply a non-stop workﬂ ow from volume production

down to batch size one. With just a single operator,

you can maintain continuous production under all

circumstances, thanks to software-driven proactive

replenishment and complete material tracking. And

with all of this in a single vendor, it’s also possible to

reduce training and maintenance costs while allow-

ing for higher degrees of freedom in sta ng and

planning decisions.

MY300DX – MORE CAPACITY IN LESS SPACE

With 448 feeder positions per line, the MY300DX-17

gives you a full 40% more feeder capacity per meter

of line length than previous generations. Or take ad-

vantage of the MY300’s smaller footprint by incor-

porating additional process steps in your line, should

the need arise. With 18 nozzles per machine, you will

be capable of mounting a vast mix of component

types, resulting in excellent throughput.

SMD TOWER – AUTOMATED

NEAR-PRODUCTION STORAGE

The SMD Tower is a highly ﬂ exible, automated and

expandable bu er storage unit. Designed for near-

production deployment, it ensures that the right

components remain stored in the correct place and in

a controlled atmosphere, always ready for a quick and

smooth line changeovers. With just one-and-a-half

square meters of ﬂ oor space, it can store up to 958

reels while recording all movements and quantities.

Combine two MY300DX lines in a single workcell, and you have a full

160,000 CPH placement capacity at your control. For continuous

high-speed production this means a proactive, fully automated material

ﬂ ow, run by fewer operators.

From high capacity

workcell down

to batch size one

MY300DX-13/17

High-capacity workcell. Two MY300DX

lines including the SMD Tower for

automated near-production storage.

HIGH CAPACITY

KEY BENEFITS

- 160,000 CPH within one workcell

- On-the-ﬂ y changeovers

- Near-production storage and

automated replenishment

- Electrical veriﬁ cation of resistors,

capacitors, diodes and transistors

- Full traceability

10 11

Whichever conﬁ guration you choose, you’ll be

able to reduce production costs and delivery times

thanks to high speeds, high feeder counts and full

visibility planning. And because all equipment is

based on a single platform and source, software

packages can be added as needed, always ensuring

full traceability down to PCB ID level.

TECHNOLOGY THAT STANDS THE TESTS OF TIME

Mycronic o ers a range of value-added packages

specially tailored to the demands of subcontractors.

This includes a fully future-proof solution combin-

ing software with services such as operator training

courses, production and process support as well

as process and knowledge courses. With the right

training and the right equipment, your investments

will pay o for years to come.

HANDLE ANY FUTURE COMPONENT

Thanks to a new x-wagon with updated high-speed

mountheads and up to 4k resolution vision systems,

the MY300DX reaches top speeds of up to 40,000

components per hour and handles nearly any com-

ponent you might need for years to come. The mod-

el’s 18 nozzles, together with 448 feeder positions in

one line, ensure excellent throughput for any mix of

component types.

SPEED UP YOUR SET-UPS

Package deﬁ nition can be created in seconds using

the AutoTeach function. Just show the unknown

package to the vision system, and all geometri-

cal data is measured automatically – saving you a

signiﬁ cant amount of time when setting up new

jobs. Together with an improved 2k or 4k resolution

linescan camera, this makes it faster to handle an

immense range of new miniaturized and specialized

components.

For those who demand versatility, two MY300DX machines arranged into a

single line form an agile, modular production unit capable of meeting any

future needs. Thanks to a more space-e cient design, it now packs in a full

40% more feeder capacity within the same line length as previous models.

The high-mix workhorse

- now with 40% more feeders

MY300DX-17

Flexible high-capacity line. MY300DX-17

Synergy line rated at 80,000 CPH with

448 feeder positions.

HIGH-MIX

KEY BENEFITS

- 80,000 CPH with up to

448 feeder positions

- A complete SMT assembly

solution from a single source

- Fastest changeovers

in the industry

- Full traceability

12 13

AUTOMATION DOWN TO THE SMALLEST DETAIL

Mycronic’s planning software makes it possible

to analyze hundreds of work orders and organize

them into family kits, perfectly sized to ensure

hours of non-stop production. With the help of

proactive replenishment notiﬁ cations, you’ll ﬁ nally

be able to close the e ciency gap between volume

and short-series production. Now with automated

board train functionality, job selection and convey-

or width, you’ll also beneﬁ t from operator-inde-

pendent production with completely centralized

programming.

BUILD PRODUCTS, NOT INVENTORY

With changeovers this easy, any job is possible.

Batch sizes can be optimized for downstream

operations including inspection, testing and box

build. And instead of building stock inventory,

you can build-to-order, thereby reducing risk and

working capital while removing the risk of old-revi-

sion products.

MY300SX – THE FUTURE OF FLEXIBILITY

At up to 24,000 CPH, the MY300SX gives you the

ﬂ exibility you need to tackle tomorrow’s challenges.

It is ideal for high-mix production, handling up to

192 feeders and an endless variety of components.

Advanced mountheads, state-of-the-art vision

systems and a wide selection of conveyor sizes all

ensure that the line is able to accommodate a range

of board sizes, shapes and technologies. Based on

the same technology platform as the MY300DX, the

MY300SX features a single mounthead carrier that

picks components from both sides of the machine.

This provides incredible ﬂ exibility while maintain-

ing the ability for on-the-go setups and seamless

changeovers from one production run to another.

The high-precision linear drive and distributed servo

technology provide the ability to increase through-

put, while continuous accuracy calibration maintains

the high level of quality that you would expect from

a Mycronic machine.

As batch sizes shrink and the number of process steps expands, uptime

doesn’t have to su er. By combining software-driven solder paste and

assembly ﬂ uid application with high feeder capacity, continuous opera-

tion is both easy and economical – down to small batch sizes, or even a

single board.

Fully automated short

series production

FULLY AUTOMATED

KEY BENEFITS

- Full component range

in one machine

- Fastest set-ups and

changeovers in the industry

- Capable of pin-in-paste, PoP,

QFN, board cavities and more

- Stencil-free printing

- The world’s fastest assembly

ﬂ uid dispensing system

- On-the-spot board revisions

- Handle short tape strips and

nonstandard carriers

MY300SX-11/15

Automated short series production.

MY700JX in-line with a MY300SX.
