1 1766C011010 BRACKET 1 2 KXFP4UQAA00 CAMERA CCD63-TR3 1 3 KXF08D9AA00 LENS KOK-91LE 1 4 KXF07RPAA00 LIGHT M09-9L 1 5 1766C081040 LED-LAMP-UNIT LED-VK(only LED light source and power source) 1 6 1766C061010 PLATE 1 7 KXF…
1 1766C011010 BRACKET 1
2 KXFP4UQAA00 CAMERA CCD63-TR3 1
3 KXF08D9AA00 LENS KOK-91LE 1
4 KXF07RPAA00 LIGHT M09-9L 1
5 1766C081040 LED-LAMP-UNIT LED-VK(only LED light source and power source) 1
6 1766C061010 PLATE 1
7 KXF07UJAA00 SPACER BSF-410 4
8 KXF07UKAA00 SPACER BSF-480 8
9 1766C011020 COVER 1
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
NO
番号
ＭＯ機番
ユニット名称
ﾏｽｸ認識部:SP20P-MA1
UNIT NAME
PART NUMBER
品番 部品名 型式 数量 ﾗﾝｸ 備考
Mask recognition section: SP20P-MA1
PART LIST
MODULE NUMBER
パーツリスト
1766C0M0000
5
UNIT NUMBER
ユニットＮｏ.
PART NAME TYPE Q'TY RANK REMARKS
− −42 02 0005−（ ）
