Page SAMSUNG TECHWIN 299 DECAN L2 Axis IO Board (15/16) NO. P ART NO. P ART NAME Q'TY Old No. Supply Supply L T Reference 1 AM03-01 1 153A CABLE ASSY -EX_CV_32P_MODULE _B_FULL 1 2 AM03-01 1244A CABLE A SSY -EX_CV_FU…
Page
SAMSUNG TECHWIN
298
DECAN
L2
Axis IO Board (15/16)
Page
SAMSUNG TECHWIN
299
DECAN
L2
Axis IO Board (15/16)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 AM03-011153A CABLE ASSY-EX_CV_32P_MODULE_B_FULL 1
2 AM03-011244A CABLE ASSY-EX_CV_FULL_DUAL_LONG 1
3 AM03-011155B CABLE ASSY-EX_CV_F_R_PCB_SEN_FULL 1
4 AM03-011150A CABLE ASSY-CV_BELT_STEP_MOTOR_FULL 1
Page
SAMSUNG TECHWIN
300
DECAN
L2
Axis IO Board (16/16)
