Page SAMSUNG TECHWIN 297 DECAN L2 Axis IO Board (14/16) NO. P ART NO. P ART NAME Q'TY Old No. Supply Supply L T Reference 1 AM03-01 1 15 1B CABLE ASSY -IN_CV_30P_MODUL E_B_FULL 1 2 AM03-01 1244A CABLE A SSY -EX_CV_F…
Page
SAMSUNG TECHWIN
296
DECAN
L2
Axis IO Board (14/16)
Page
SAMSUNG TECHWIN
297
DECAN
L2
Axis IO Board (14/16)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 AM03-011151B CABLE ASSY-IN_CV_30P_MODULE_B_FULL 1
2 AM03-011244A CABLE ASSY-EX_CV_FULL_DUAL_LONG 1
3 AM03-011149B CABLE ASSY-IN_F_PCB_SEN_IN_WAIT_FULL 1
4 AM03-011150A CONV_BELT3_STEP_MOTOR_ASSY 1
Page
SAMSUNG TECHWIN
298
DECAN
L2
Axis IO Board (15/16)
