Page SAMSUNG TECHWIN 364 DECAN L2 Nozzle /JIG
Page
SAMSUNG TECHWIN
363
DECAN
L2
Articles of Consumption
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 AM03-006409A CABLE ASSY-CABLE ASSY-LR_ZR_DRV_FAN 2 3 Years
2 HP04-000178 FILTER-PF3-03D 3 Years
3 HP04-000179 FILTER,OIL-PFH3-03D 3 Years
4 HP11-000193 PUMP-KHF-14-V-01 6 Month
5 J90833316A FAN_CABLE_ASSY SM-FAN00 3 Years
6 EP02-001745B HARNESS-V1+ LOOF FAN CABLE ASSY 3 Years
7 J90833316A FAN_CABLE_ASSY SM-FAN00 3 Years
8 J90833316A FAN_CABLE_ASSY SM-FAN00 3 Years
9 EP10-900438 FUSE[250V 5A] Breakdown
10 EP10-900439 FUSE[250V 10A] Breakdown
11 MC05-900056 BELT_WIDTH_SYNC 025-XL-286AJ 6 Month
12 MC05-900058 TIMMING_BELT_WIDTH 180-3GT-9 6 Month
13 MC05-900057 BELT_WORK MAM-5P-1550-6W 6 Month
14 MC05-000151 TIMING BELT-TIMING-BELT-1491-3GT-20;3GT 6 Month
15 MC05-000068A BELT-SHUTTLE_MAM;FLAT,945,6W,1.2MM 6 Month
16 MC05-000234 BELT-MAM-5P-1504-6W;FLAT,1504,6,1.2 6 Month
17 J7055140A STEEL BALL [DIA2, SUS304] 1 Years
18 J72550021C SILICON TUBE(BLACK) 1 Years
19 HP04-900036 SUCTION_FILTER VYF44-M-50M 3 Month
Page
SAMSUNG TECHWIN
364
DECAN
L2
Nozzle /JIG
Page
SAMSUNG TECHWIN
365
DECAN
L2
Nozzle /JIG
NO. PART NO. Part NAME Q'TY Old No. Supply Supply LT Reference
1 J90551006A NOZZLE_CN020_ASSY 1
2 J9055133C NOZZLE CN030 ASSY 1
3 J9055134C NOZZLE CN040 ASSY 1
4 J9055136C NOZZLE CN065 ASSY 1
5 J9055159B NOZZLE CN140 ASSY 1
6 J9055351A NOZZLE CN220 ASSY(CERAMIC) 1
7 J90551072A NOZZLE_CN400_ASSY 1
8 TO04-001051A SM511 HEAD PIN HEIGHT_MASTER JIG 1
9 FC14-000925A NOZZLE-BODY_CN030 1 J70550406D
10 FC14-000924A NOZZLE-BODY_CN110 1 J70550574C
11 FC14-000922A NOZZLE-BODY_CN400 1 J70550572C
12 FC14-000923A NOZZLE-BODY_ CN750 1 J70550573C
13 FC14-000926A NOZZLE-BODY_CALIBEATION_TOOL 1 J70550575B
