30 13連供 給 連結 部 :NP M-T T 13-Slot Supply Connection Part:NPM -TT パーツレイアウト Ki t N o . キット 品番 Kit N am e キット名称 N610136571AA ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - O101 ( KN610136571AA-03 )
Ref
No.
Remarks
R
1
Q'ty
29-B
13連供
給
リールホルダ
部
:NPM-W
13-Slot Supply Reel Holder Part:NPM-W
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610124211AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
HOLDER
1
1 N210028658AA
HOLDER
1
2 KXFB02ESA00
BAR
1
3 N210143967AA
SHEET
1
4 N210102928AA
FRAME
1
5 N210143970AA
BRACKET
1
6 N210143972AA
COVER
1
7 N210147261AB
BOX
1
8 N210147262AA
CASTER
2
9 N510057142AA 415A-30R 40mm M12(P1.25)
CASTER
2
10 N510052845AA V20200A0000
KNOB
2
11 KXF024LAA00 GK40X10
BOLT
13
12 N510042998AA
SSS 003 Hexagon socket button head screw M4X6-10.9 A2S (Trivalent)
NUT
4
13 N510018925AA
Hexagon nut Type-3 Best class M12X1.25-6H-4T A2J (Trivalent)
WASHER
4
14 N510018507AA
Round finish plain washer 12 10H A2J (Trivalent)
BOLT
2
15 N510017568AA
SSS 003 Hexagon socket button head screw M6X8-10.9 A2S (Trivalent)
NUT
2
16 N510017875AA
Hexagon nut Type-3 Middle class M6-6H-4T A2S (Trivalent)
PACKING
4
17 KXF0E1KJA00 C-300-EF-3-20
O100
--
( KN610124211AA-02-2 )
30
13連供
給
連結
部
:NPM-TT
13-Slot Supply Connection Part:NPM-TT
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610136571AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
O101
( KN610136571AA-03 )
Ref
No.
Remarks
R
1
Q'ty
30
13連供
給
連結
部
:NPM-TT
13-Slot Supply Connection Part:NPM-TT
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610136571AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
BLOCK
1
1 N210161201AA
BLOCK
1
2 N210161202AB
COVER
1
3 N210151744AA
COVER
1
4 N210168077AA
COVER
1
5 N210162150AB
CHUTE
1
6 N210161204AB
BRACKET
2
7 N210162151AA
COVER
1
8 N210144071AB
PLATE
2
9 N210144072AA
BRACKET
1
10 N210161205AA
CHUTE
1
11 N210144074AB
CHUTE
1
12 N210144075AC
PLATE
1
13 N210153353AA
BRACKET
1
14 N210146765AA
NUT-PLATE
1
15 N210146766AA
FRAME
1
16 N610136580AC
SENSOR(2000mm)
1
17 N610123991AC
PIN
4
18 N510020618AA MMS6-15
SCREW
8
19 N510018300AA
Cross recessed Truss head machine screw M5X6-4.8 A2J (Trivalent)
PIN
2
20 N510020631AA MMS8-25
BOLT
4
21 N510017535AA
SSS 003 Hexagon socket button head screw M4X8-10.9 A2S (Trivalent)
PIN
2
22 KXF0CXHAA00 1017003-40008
SCREW
2
23 N510018285AA
Cross recessed Truss head machine screw M5X10-4.8 A2S (Trivalent)
WASHER
2
24 N510018765AA
Toothed lock washer 5 External toothed Steel Unichrome white (Trivalent)
FILTER
1
25 N510058863AA E39-E14-1
BOLT
2
26 N510022988AA
Hexagon socket head cap screw M2X14-10.9 A2J (Trivalent)
WASHER
2
27 N510018477AA
Small round-plain washer 2 10H A2J (Trivalent)
WASHER
2
28 N510018324AA Spring lock washer No.2 2 S A2J (Trivalent)
LABEL
1
29 N986PC0106M1
S
PC0106M1
TAPE
1
30 KXF0DXNAA00 AGF-100 t=0.18 W=100mm L=10m
JOINT
4
31 KXF09ZBAA00 KQ2P-06
BRACKET
1
32 N210168076AA
GROMMET
1
33 N510056320AA MG-10
SWITCH
2
34 N510057874AA
S
HS5D-03RNP
BOLT
4
35 N510001582AA SRBS-M4X30
JOINT
2
36 KXF06F4AA00 53015030-WM
O102
--
( KN610136571AA-03 )
