VisionX -Series Convection Soldering E fcient and power ful in ev ery production ambience Reflow convection soldering with flexibility and high throughput
VisionX-Series
Convection Soldering
Efcient and powerful
in every production ambience
Reflow convection soldering with flexibility and high throughput
2
VisionX-Series
Reow soldering with convection
Diversity with the VisionX-Series
Whether laptop, smartphone or in-car control systems – almost every techni-
cal end product contains sensitive electronics. The contacting of the electrical
components on the circuit board using high-quality soldering is crucial when
it comes to guaranteeing smooth function. Rehm Thermal Systems works to
develop reow soldering systems for your production which can be integrated
seamlessly into the manufacturing environment.
Systematically applied technology and superb construction are the features of our
convection reflow soldering systems. In the VisionX-Series the soldering process
is performed on the basis of convection – that is, the transfer of heat via a flow of
gases. Our systems are available in air or nitrogen versions. As an inert, protective
gas, nitrogen is the ideal heat transfer medium and prevents disturbing oxidation
during the soldering process. The modular system conguration of the VisionX-
Series also offers a high level of flexibility for your production facility.
Convection
Soldering
Without fail to the right quality
VisionX-Series
NEW! VisionXP+ Vac
Convection soldering with vacuum
›
The 2-in-1 solution for voidfree reflow soldering
›
Reliable reflow soldering process
› Vacuum down to 2 mbar for reducing the num-
ber of voids in the solder joints
› Removes pores and voids immediately after the
soldering process reliably and vibration free
VisionXS
Convection soldering for Mid-Range applications
› Modular system concept
› Efficient heat transfer
› Stable process for lead-free applications
› Minimal downtime
› Integrated residue management
› User-friendly software tools for process monitoring
VisionXC
Convection soldering with compact design
› Optimized heat transfer and thermal stability
›
Excellent process performance at minimal space
›
Efcient residue management system for a clean
process chamber
VisionXP+
High-End convection soldering
›
Efficient reflow convection soldering process
at highest process stability
›
Industry 4.0 ready due to numerous software
tools
›
Flexible transport systems
›
Efficient residue management with pyrolysis
›
Highest energy efficiency with reflow soldering
The VisionX-Series
As individual as your production
Does your production environment need a compact system which can be adapted optimally to your requirements?
Do you process sensitive electronic components which need to correspond to certain temperature conditions? Or
would you like a system that can solder void-free under a vacuum? We have a diverse range of products!
