20 Industry 4.0 Intelligent Software Solutions Software solutions from Rehm allow the reliable control and monitoring of systems from the VisionX -Series. The software components are consisting of monit oring tools and v…
19
Clear product management with offline programming
Intuitive software operation with touch-screen surface
Clear product management with oine programming
Parameter transparency through module groupings
Easy adaption due to favourites bar
Multilingual software
Innovative software
User-friendly and easy operation
With the ViCON Rehm offers straightforward software for
the VisionX-Series, boasting intuitive operation with its
touch-screen surface.
All messages, commands and parameters can be viewed
at one glance on the main screen using machine view. With
a number of features including a freely congurable favour-
ites bar, the structured grouping of parameters or individual
process tracking and documentation ViCON provides you with
optimum assistance in your production processes.
While developing the software Rehm experts have rened many
aspects including product management. The creation of new
products or the copying of certain properties in parallel with
production on the machine is enabled. The parameters for new
creations are directly selectable, meaning that the production
sequence can progress faster and without any disruption.
As well as that, you can immediately recognise which action
mode the system is in from the operating status. Errors are
easier to differentiate and alarm messages can be evaluated
quickly and reliably.
Another plus of the ViCON is dening user administration.
Through the assignment of specic user roles each user has
exactly those rights activated that he or she needs for opera-
tion and work on the system – without any rigid hierarchy.
VisionX-Series | Software
20
Industry 4.0
Intelligent Software Solutions
Software solutions from Rehm allow the reliable control and monitoring of systems from
the VisionX-Series.
The software components are consisting of monitoring tools and various modules, each of
which completes its own individual task. Master software compiles the data and evaluates
it, for instance in order to keep the specied parameters constant for the respective manu-
facturing prole. The modular system can be assembled into individualized packages and
matched to the customer’s respective requirements. Custom tailored master software is
available for each system type.
4.0
Industry
21
VXP+ VXS VXC
VXP+
Vac
VXP+ VXS VXC
VXP+
Vac
VXP+ VXS VXC
MES connection and ROI
Long-standing experience with MES connections makes it
possible for Rehm to offer an innovative solution for MES
master computer connection which meets every known re-
quirement of modern MES systems. Communication here is
based on XML logs transmitted via TCPIP. All data relating to
process interlocking, traceability, machine status and other
operating data is exchanged here.
Clearly structured product management ensures in everyday
production that the right reflow program is clearly attributed to
the component/item number to be manufactured. Alongside
the oven settings, component-specic data can also be saved
in product management.
Product management
A variety of packages are possible for the VisionX design
series in the eld of traceability and process interlocking:
› Traceability / Process traceability via hand-held
scanner (order-specific)
› Process interlocking via fixed position scanners
› Process interlocking and traceability via fixed
position scanners
A data set containing the relevant process parameters
during the process is generated in a le for each component
as a basis for all packages. Depending on the package, the
components can, using the barcode scan, be identied on the
component directly or using a routing slip scan (by hand or
stationary). If the package contains process interlocking too,
the scan is compared with the database and the component
is only transported into the oven upon release. With the
traceability option, a data set containing the relevant process
parameters during the process is generated in a le for each
soldered component.
Traceability and process interlocking
Optimal
tracking
ProCap
ProCap guarantees the process stability of the reflow
soldering system for each individual product. The process
parameters are automatically stored for the product upon rst
start-up. Every additional order is compared with the param-
eters stored for this product. Each individual component is
saved to the ongoing product and order and, where applica-
ble, order numbers and serial numbers are stored along with
these. Process deviations and operator errors are logged too.
Gradual changes such as, for example, a clogged lter are
reliably detected.
VXP+
Vac
VXP+ VXS VXC
