CM400-M Mechanical Parts - 第40页
1-I 本体部 Main Body パーツレイアウト Kit No. キット品 番 Kit Name キット名称 N610000774AA ｾｸｼｮﾝNo. PARTS LAYOUT Section No. M17
Ref
No.
Remarks
R
1
Q't
y
1-H
本体部
Main Body
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit No.
キット品
番
Kit Name
キット名称
N610000774AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
HOLDER
1
1 N210058099AA
BLOCK
1
2 KXFB09VAA00
HOLDER
1
3 KXFB09VBA01
BRACKET
1
4 N210009650AA
HOLDER
1
5 KXFB02GGA01
COLLAR
1
6 KXFB00T1A00
BUSHING
2
7 KXFB01GBA00
COVER
1
8 N210028680AA
SPACER
1
9 KXFB09WFA00
BALL-SCREW
1
10 N510002889AA W2009-364PSSX-C3Z30
LINEAR-WAY
2
11 N510023680AA
SHS20LV1UC1S/1QZUC1S+1150LHS-II(B)(01950969G000)
BEARING
1
12 N510014709AA 7002UCDB/GNP5
BEARING
1
13 KXF0A1SAA00 7202T2DF/GNP5
BEARING-NUT
2
14 KXF00W4AA00 AN02
BEARING
2
15 KXF010WAA00 AW02
MOTOR
1
16 KXF0CWLAA00
S
HC-RFS103-S1(DDA)
PH-SENSOR
1
17 KXF0DKYAA00 PM-F44(DA 0DKYA)
PH-SENSOR
1
18 KXF0DKZAA00 PM-F44(DA 0DKZA)
JOINT
2
19 KXF029NAA00 KJS04-M5
JOINT
1
20 KXF02T9AA00 M-5HL-4
JOINT
1
21 KXF0E1Z9A00 KQ2H06-00
SPACER
1
22 N510013911AA CB-508E
PIN
1
23 KXF02YQAA00 MS6-10
JOINT
1
24 KXF0DUBAA00 KK3S-08E
JOINT
1
25 KXF0DZ94A00 KQ2H08-00
WASHER
1
26 KXF0DX46A00 WSSB30-15-5
SHIM
1
27 KXF0DX47A00 CIMR15-21-0.5
COUPLING
1
28 KXF0E10UA00 SFC-050DA-12B-24B
COVER
1
29 N210088736AA
M16
1-I
本体部
Main Body
パーツレイアウト
Kit No.
キット品
番
Kit Name
キット名称
N610000774AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
M17
Ref
No.
Remarks
R
1
Q't
y
1-I
本体部
Main Body
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit No.
キット品
番
Kit Name
キット名称
N610000774AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
BRACKET
1
1 N210028681AA
JOINT
10
2 KXF09ZBAA00 KQ2P-06
JOINT
3
3 KXF0A0DAA00 KQ2X06-08
MANIFOLD
1
4 KXF02A2AA00 KM12-08-03-10
JOINT
2
5 KXF0DZKRA00 KQ2P-08
REGULATOR
1
6 N510010273AA AWM40-03BD-R-X2108
NIPPLE
2
7 KXF0568AA00 Nipple 3/8
COVER
1
8 N210009268AA
PLUG
1
9 KXF0DHWAA00 Hexagon socket pipe plug R3/8
VALVE
1
10 KXFX061NA00
S
PRESSURE-SW
1
11 KXFX03EHA00
VALVE
1
12 N510036414AA 600RP-LL 3/8
HOSE
1
13 N510002541AA OUA8X12-5M-03B
JOINT
1
14 KXF07G7AA00 No.392 LC-3/8
PLATE
1
15 KXF0DU5AA00 VP500-2-2P
JOINT
1
16 KXF02BAAA00 KQH08-03S
SILENCER
1
17 KXF00WGAA00 AN303-03
NIPPLE
2
18 KXF0568AA00 Nipple 3/8
TEES
1
19 KXF054JAA00 Cheese 3/8
VALVE
1
20 KXF0DYX0A00 30-VP544-1D-A
SW
1
21 KXF0DWVZA00 ISE30-01-25-M-X114
JOINT
1
22 KXF0CS5AA00 KQE04-01
M18
