2-D 全体 カ バー Whole Cover パー ツレイ アウト Kit No. キ ット 品番 Kit Name キ ット 名称 N610000775AA ｾｸｼｮﾝ No . PARTS LAYOUT Section No. - - M25 ( KN610000775AA-05-4 )
Ref
No.
Remarks
R
1
Q'ty
2-C
全体
カバー
Whole Cover
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit No.
キット
品番
Kit Name
キット名称
N610000775AA
Part Name
備 考
ｾｸｼｮﾝ
No
.
PARTS LIST
Section No.
R
3
COVER
1
1 N210023272AA
COVER
1
2 KXFB03UKA00
COVER
1
3 N210027682AA
BRACKET
1
5 N210035071AB
PACKING
2
6 KXF0DKJAA00 UC-300286(DA 0DKJA)
PACKING
2
7 KXF0DKKAA00 UC-300286(DA 0DKKA)
WASHER
4
8 N510018765AA
Toothed lock washer 5 External toothed Steel Unichrome white (Trivalent)
WASHER
3
9 N510018762AA
Toothed lock washer 4 External toothed Steel Unichrome white (Trivalent)
M24
-
-
( KN610000775AA-05-3 )
2-D
全体
カバー
Whole Cover
パーツレイアウト
Kit No.
キット
品番
Kit Name
キット
名称
N610000775AA
ｾｸｼｮﾝ
No
.
PARTS LAYOUT
Section No.
-
-
M25
( KN610000775AA-05-4 )
Ref
No.
Remarks
R
1
Q'ty
2-D
全体
カバー
Whole Cover
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit No.
キット
品番
Kit Name
キット名称
N610000775AA
Part Name
備 考
ｾｸｼｮﾝ
No
.
PARTS LIST
Section No.
R
3
COVER
2
1 N210002209AA
COVER
1
2 N210002210AA
S
COVER
1
3 N210002212AA
S
COLLAR
2
4 KXFB058VA01
COVER
1
5 KXFB0EFUA00
COVER
1
6 N210005053AA
BRACKET
1
7 N210022148AA
S
BRACKET
1
8 N210022149AA
S
COVER
1
9 N210028714AB
S
COVER
1
10 N210028715AB
S
COVER
1
11 N210028716AA
S
BRACKET
1
12 N210028719AA
S
COVER
1
13 KXFB09Z8A00
COVER
1
14 N210005054AB
COVER
1
15 N210020903AA
BRACKET
2
16 N210013325AB
COVER
1
17 N610007336AA
COVER
1
18 N610003559AA
COVER
1
19 N610003569AA
COVER
1
20 N610003570AA
COVER
1
21 N610003574AA
CAP
4
22 KXF0DLNAA01 CP-328-B-4-ivory(DA KXF0DLNAA01)
BOLT
4
23 N510017614AA
Hexagon socket Flat head bolt M4X10-10.9 A2J (Trivalent)
POST
2
24 N510007205AA LSBWRKT-12-63
CAP
24
25 KXF0DLPAA01 CP-328-B-6 hole process ivory(DDA)
BOLT
24
26 N510017647AA
Hexagon socket Flat head bolt M6X16-10.9 A2J (Trivalent)
WASHER
4
27 N560L0WA8 LOWA8
MAGNET
3
28 KXF0CS8AA00 C-54-2-black
WASHER
2
29 KXF0CXEAA00 URWH12-8-5
WASHER
4
30 N510018469AA
Iron round plain washer4X10X1.0 A2J (Trivalent)
SPACER
2
31 N510017097AA CB-405E
SCREW
4
32 N510018233AA
Cross recessed Truss head machine screw M3X10-4.8 A2S (Trivalent)
SCREW
2
33 N510018266AA
Cross recessed Truss head machine screw M4X16-4.8 A2S (Trivalent)
SCREW
10
34 N510018283AA
Cross recessed Truss head machine screw M4X8-4.8 A2S (Trivalent)
BOLT
2
35 KXF0DYG5A00 GUTB4-5-10
SCREW
6
36 N510018280AA
Cross recessed Truss head machine screw M4X6-4.8 A2S (Trivalent)
COLLAR
2
37 N210071617AA
BRACKET
1
38 N210076015AA
DOG
1
39 N210075609AA
WASHER
2
40 N510030285AA 87WASBH8-3
M26
-
-
