SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 112 of 241 ©Siemens AG, all rights reserved
4.5 Stream 3
not used
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 113 of 241
4.6 Stream 4
not used
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 114 of 241 ©Siemens AG, all rights reserved
4.7 Stream 5
4.7.1 S5F1 - Alarm Report
{XE "S5F1"}S5F1 [W] * H<-E
<L [3]
<B [1] {XE "ALCD"}ALCD> * ALCD - Alarm On/Off and Severity
<U4 {XE "ALID"}ALID> * ALID - Alarm ID
<A [40] {XE "ALTX"}ALTX> * ALTX - Alarm Text
> .
This message is the "normal" message that the Equipment uses to report alarms. In
order for this message to be used, the Equipment Constant "ConfigAlarms" must be set
to "0".
If the Equipment Constant "{XE "ConfigAlarms"}ConfigAlarms" is set to "0", the
Equipment sends S5F1 instead of the normal S5F73 Alarm Notification Send.
The equipment reports that an alarm condition has changed.
ALID identifies the Alarm.
The high-order bit of ALCD will be "1" if this alarm is currently On (Unsafe), or "0" if it is
currently Off (Safe). The low-order seven bits of ALCD contain the severity code for this
alarm.
ALTX contains up to 40 bytes of Alarm Text. See "Appendix C" for a table of possible
Alarms which can occur.
Equipment Constant "{XE "WBitS5"}WBitS5" controls whether the Equipment sends
S5F1 with W-Bit "1" (Reply Expected) or "0" (No Reply Expected).
4.7.2 S5F2 - Alarm Acknowledge
{XE "S5F2"}S5F2 * H->E
<B [1] 00>. * ACK5 - Alarm Acknowledge
The Host acknowledges the Alarm Report. This Equipment ignores the {XE
"ACKC5"}ACKC5.
4.7.3 S5F3 - Enable/Disable Alarm
{XE "S5F3"}S5F3 [W] * H->E
<L [2]
<B [1] {XE "ALED"}ALED> * ALED - Alarm Enable/Disable Code
<U4 {XE "ALID"}ALID> * ALID - Alarm ID
> .
The Host commands the Equipment to enable or disable (depending on ALED) reporting
for the specified Alarm ID in S5F1, S5F8, S5F71, and S5F73.
ALED Description
0x80 Enable sending alarm.
0x00 Disable sending alarm.
