SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 163 of 241
6 Variables
All Ids on SIPLACE are 6 or 7-digits long. The last 3 digits are a consecutively increasing
integer. The next two digits distinguish between errors, event and variables (0:Event,
1:ErrorEvent; 2:Variable) and the software component (0:GEM, 1:Realtimesoftware;
2:Stationsoftware). The first 2 represent the „object“ on which the event occurs.
Example:
6 1 2 007 (Transportwidth)
The objects are :
ObjectId Name
1 Software
2 Nozzle Changer
3 Axis
4 Fiducials
5 Vision
6 Transport
7 Coplanarity
8 Matrix Tray Changer (MTC)
9 Barcode
10 GEM-Kernel
11 User Interface / Operator
12 CAN-Bus
13 Head 1
14 Head 2
16 Data Preparation
17 Trolleys
18 Glue Machine
19 CRDL Measurement
20 Miscellaneous
21 Flux
23 Head 3
24 Head 4
Object: Transport
Realtimesoftware
Variable
Number
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 164 of 241 ©Siemens AG, all rights reserved
ObjectId Name
25 Traceability
VID Class Forma
t
Name and Description
Fiducials
412002 SV L
{ XE FIDUCIALDATA }FIDUCIALDATA
Result from the last fiducial measurement
<L
<U1 FiducalName>
<I1 Quality> [1 - 100]
<U4 X-position> [1/1000 mm]
<U4 Y-position> [1/1000 mm]
<U4 X-deviation> [1/1000 mm]
<U4 Y-deviation> [1/1000 mm]
>
In case of an ink spot x-position, y-position, x-
deviation, y-deviation and quality are not valid.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
SIPLACE Transport
612001 SV U1
{ XE INPUTCONVEYORSTATE
}INPUTCONVEYORSTATE
The state of the input conveyor.
0 = Empty
1 = Full
2 = Error
612012 SV U1
{ XE FIRSTPROCESSINGCONVEYORSTATE
}FIRSTPROCESSINGCONVEYORSTATE
The state of the first processing conveyor.
0 = Empty
1 = Full
2 = Error
612013 SV U1
{ XE INTERMEDIATECONVEYORSTATE
}INTERMEDIATECONVEYORSTATE
The state of the intermediate conveyor
0 = Empty
1 = Full
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 165 of 241
VID Class Forma
t
Name and Description
2 = Error
612014 SV U1
{ XE SECONDPROCESSINGCONVEYORSTATE
}SECONDPROCESSINGCONVEYORSTATE
The state of the second processing conveyor.
0 = Empty
1 = Full
2 = Error
612003 SV U1
{ XE OUTPUTCONVEYORSTATE
}OUTPUTCONVEYORSTATE.
The state of output conveyor.
0 = Empty
1 = Full
2 = Error
612004 SV U1
{ XE TWININPUTCONVEYORSTATE
}TWININPUTCONVEYORSTATE.
The state of the input conveyor on twin side
0 = Empty
1 = Full
2 = Error
612022 SV U1
{ XE TWINFIRSTPROCESSINGCONVEYORSTATE
}TWINFIRSTPROCESSINGCONVEYORSTATE
The state of the first processing conveyor on twin side
0 = Empty
1 = Full
2 = Error
612023 SV U1
{ XE TWININTERMEDIATECONVEYORSTATE
}TWININTERMEDIATECONVEYORSTATE
The state of the intermediate conveyor on twin side
0 = Empty
1 = Full
2 = Error
612024 SV U1
{ XE SECONDPROCESSINGCONVEYORSTATE
}SECONDPROCESSINGCONVEYORSTATE
The state of the second processing conveyor on twin
side
0 = Empty
1 = Full
2 = Error
612006 SV U1
{ XE TWINOUTPUTCONVEYORSTATE
}TWINOUTPUTCONVEYORSTATE.
