SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 164 of 241 ©Siemens AG, all rights reserved
ObjectId Name
25 Traceability
VID Class Forma
t
Name and Description
Fiducials
412002 SV L
{ XE FIDUCIALDATA }FIDUCIALDATA
Result from the last fiducial measurement
<L
<U1 FiducalName>
<I1 Quality> [1 - 100]
<U4 X-position> [1/1000 mm]
<U4 Y-position> [1/1000 mm]
<U4 X-deviation> [1/1000 mm]
<U4 Y-deviation> [1/1000 mm]
>
In case of an ink spot x-position, y-position, x-
deviation, y-deviation and quality are not valid.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
SIPLACE Transport
612001 SV U1
{ XE INPUTCONVEYORSTATE
}INPUTCONVEYORSTATE
The state of the input conveyor.
0 = Empty
1 = Full
2 = Error
612012 SV U1
{ XE FIRSTPROCESSINGCONVEYORSTATE
}FIRSTPROCESSINGCONVEYORSTATE
The state of the first processing conveyor.
0 = Empty
1 = Full
2 = Error
612013 SV U1
{ XE INTERMEDIATECONVEYORSTATE
}INTERMEDIATECONVEYORSTATE
The state of the intermediate conveyor
0 = Empty
1 = Full
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 165 of 241
VID Class Forma
t
Name and Description
2 = Error
612014 SV U1
{ XE SECONDPROCESSINGCONVEYORSTATE
}SECONDPROCESSINGCONVEYORSTATE
The state of the second processing conveyor.
0 = Empty
1 = Full
2 = Error
612003 SV U1
{ XE OUTPUTCONVEYORSTATE
}OUTPUTCONVEYORSTATE.
The state of output conveyor.
0 = Empty
1 = Full
2 = Error
612004 SV U1
{ XE TWININPUTCONVEYORSTATE
}TWININPUTCONVEYORSTATE.
The state of the input conveyor on twin side
0 = Empty
1 = Full
2 = Error
612022 SV U1
{ XE TWINFIRSTPROCESSINGCONVEYORSTATE
}TWINFIRSTPROCESSINGCONVEYORSTATE
The state of the first processing conveyor on twin side
0 = Empty
1 = Full
2 = Error
612023 SV U1
{ XE TWININTERMEDIATECONVEYORSTATE
}TWININTERMEDIATECONVEYORSTATE
The state of the intermediate conveyor on twin side
0 = Empty
1 = Full
2 = Error
612024 SV U1
{ XE SECONDPROCESSINGCONVEYORSTATE
}SECONDPROCESSINGCONVEYORSTATE
The state of the second processing conveyor on twin
side
0 = Empty
1 = Full
2 = Error
612006 SV U1
{ XE TWINOUTPUTCONVEYORSTATE
}TWINOUTPUTCONVEYORSTATE.
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 166 of 241 ©Siemens AG, all rights reserved
VID Class Forma
t
Name and Description
The state of output conveyor on twin side.
0 = Empty
1 = Full
2 = Error
612007 SV I4
{ XE TARNSPORTWIDTH }TRANSPORTWIDTH
transport width [1/1000 mm]
A value of -1 indicates an error
Only valid after width has been measured or adjusted
by line computer
612008 SV I4
{ XE TWINTRANSPORTWIDTH
}TWINTRANSPORTWIDTH
transport width [1/1000 mm] on twin side
A value of -1 indicates an error
Only valid after width has been measured or adjusted
by line computer
Matrix Tray Changer (MTC)
812002 SV L
{ XE MTCINFO }MTCINFO
<L
<U1 MTC_number> valid for all MTC Events
<I2 tower>
<I2 carrier_modul>
<I2 level>
<I2 division>
<I4 Filling_level>
>
If you have several MTCs you can identify a MTC by
MTC_number. A MTC has 2 towers (1,2) and on
every tower there are several carrier modules. A
carrier module contains several tray carriers. Each
tray carrier can be identified by a level number. A tray
carrier consists of many divisions, wich can be
identified by the division number.
Filling_level is only valid with the Event
MTCfillLevelChanged.
In case of the Event MTCfillLevelChanged
carrier_modul will be -1.
Barcode
912002 SV A
{ XE BCININPUTCONVEYOR
}BCININPUTCONVEYOR
Barcode read from PCB in input conveyor. If no
barcode reader is installed in SIPLACE this variable
will contain an empty text
