SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 168 of 241 ©Siemens AG, all rights reserved
VID Class Forma
t
Name and Description
2: down
3: barcode reader manufctured by LEUTZE in use
or
the barcode could not be read
912017 EC U1
{ XE BCREADEREXIST }BCREADEREXIST
Unables/Enables the event messages of the BCread
and BCTwinRead events.
0: No BCread and BCTwinRead events send
1: BCread and BCTwinRead events send (default)
912021 SV A PCBBCProc1Conv1
Barcode of PCB in progress in processing area 1 on
conveyor 1.
If no barcode reader is installed or no PCB is in
progress this variable will contain an empty text.
912021 SV A PCBBCProc1Conv2
Barcode of PCB in progress in processing area 1 on
conveyor 2.
If no barcode reader is installed or no PCB is in
progress this variable will contain an empty text.
912021 SV A PCBBCProc2Conv1
Barcode of PCB in progress in processing area 2 on
conveyor 1.
If no barcode reader is installed or no PCB is in
progress this variable will contain an empty text.
912021 SV A PCBBCProc2Conv2
Barcode of PCB in progress in processing area 2 on
conveyor 2.
If no barcode reader is installed or no PCB is in
progress this variable will contain an empty text.
GEM-Kernel
1002001 DV A
{ XE GEMEVENTTEXT }GEMEVENTTEXT.
The equipment will set this string to contain a
description of the most recent event. The Host can
include this variable in any event report it defines.
Communication Model
1002002 EC U1
{ XE INITCOMMSTATE }INITCOMMSTATE.
Initial (power-up) Communications State.
0 = Disabled
1 = Enabled
1002003 EC U2
{ XE ESTABLISHCOMMUNICATIONSTIMER
}ESTABLISHCOMMUNICATIONSTIMER.
Time in seconds of how long the equipment will pause
after an unsuccessful Connect Request before
sending another. Valid values are 0-32000.s
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 169 of 241
VID Class Forma
t
Name and Description
1002004 EC U1
{ XE CONFIGCONNECT }CONFIGCONNECT.
An EC which controls which SECS message this
Equipment will use for Connect Request.
0 = S1F1
1 = S1F65
2 = S1F13
Control State Model
1002005 EC U1
{ XE INITCONTROLSTATE }INITCONTROLSTATE.
Initial (power-up) control superstate.
1 = Off-Line
2 = On-Line
1002006 SV U1
{ XE CONTROLSTATE }CONTROLSTATE.
The current Control State.
1 = Off-Line/Equipment Off-Line
2 = Off-Line/Attempt On-Line
3 = Off-Line/Host Off-Line
4 = On-Line/Local
5 = On-Line/Remote
1002007 SV U1
{ XE PREVIOUSCONTROLSTATE
}PREVIOUSCONTROLSTATE.
The Control State in effect before the most recent
transition to the current Control State.
1 = Off-Line/Equipment Off-Line
2 = Off-Line/Attempt On-Line
3 = Off-Line/Host Off-Line
4 = On-Line/Local
5 = On-Line/Remote
1002008 EC U1
{ XE ONLINEFAILED }ONLINEFAILED.
The default Control State transition when Attempt On-
Line fails.
1 = Equipment Off-Line
3 = Host Off-Line
1002009 EC U1
{ XE ONLINESUBSTATE }ONLINESUBSTATE.
The default (power-up) online substate of the Control
State Model.
4 = Local
5 = Remote
1002010 EC U1
{ XE OFFLINESUBSTATE }OFFLINESUBSTATE.
The default (power-up) offline substate of the Control
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 170 of 241 ©Siemens AG, all rights reserved
VID Class Forma
t
Name and Description
State Model.
1 = Equipment Off-Line
2 = Attempt On-Line
3 = Host Off-Line
1002056 SV A
{ XE OPERATORCMDINRMOTESTATE
}OPERATORCMDINRMOTESTATE
The last command issued by the Operator while the
Control state is „Remote“.
An empty text indicates that there was no operator
command in remote state since the last start of the
SIPLACE.
1002057 SV U1
{ XE CONTROLMODE }CONTROLMODE
The actual control mode at the SIPLACE. This SV
indicates which software system is allowed to
download placement programs.
1 = none
2 = the „GEM-Host“
3 = the line computer (LCU)
4 = SIPLACE Pro
Process State Model
1002011 SV U1
{ XE PROCESSSTATE }PROCESSSTATE.
The current Process State.
0 = Machine Initialization
1 = Single Function
2 = Processing
1002012 SV U1
{ XE PREVIOUSPROCESSSTATE
}PREVIOUSPROCESSSTATE.
The Process State in effect before the most recent
transition to the current Process State.
0 = Machine initialization
1 = Single Function
2 = Processing
Alarm Management
1002013 SV U4
{ XE ALARMID }ALARMID.
The ALID of the most recent Alarm transition.
1002014 SV U1
{ XE ALARMSTATE }ALARMSTATE.
The Alarm State now in effect for the most recently
transitioned alarm.
0 = Alarm transitioned OFF
1 = Alarm transitioned ON
