SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 171 of 241
VID Class Forma
t
Name and Description
1002015 SV U4
{ XE ALARMSERIAL }ALARMSERIAL.
The sequence number of the most recent alarm
change (going on or going off). This number starts at
zero at power-up and increments by one for each
alarm transition which occurs.
1002016 DV A[0-40]
{ XE ALARMTEXT }ALARMTEXT.
The Alarm Text (ALTX) for the most recently
transitioned Alarm.
1002018 EC U1
{ XE CONFIGALARMS }CONFIGALARMS.
An EC which controls which Alarm Report message
this Equipment will send.
0 = S5F1
1 = S5F71
2 = S5F73
1002019 EC U1
{ XE WBITS5}WBITS5.
An EC which controls the W-Bit setting used when
sending Alarm Reports (S5F1, S5F71, or S5F73).
0 = W-Bit not set
1 = W-Bit set
1002020 SV L
{ XE ALARMSENABLED }ALARMSENABLED.
A list of all Alarms which are currently enabled.
Format as follows:
<L
<U4 ALID>
...
>
1002021 SV L
{ XE ALARMSSET }ALARMSSET.
A list of all Alarms which are currently in the SET (on)
state. Format as follows:
<L
<U4 ALID>
...
>
Time and date
1002022 SV A
{ XE CLOCK }CLOCK.
The Equipment's current Date and Time in the
following format: YYYYMMDDhhmmsscc.
YYYY = year
MM = month
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 172 of 241 ©Siemens AG, all rights reserved
VID Class Forma
t
Name and Description
DD = day
hh = hours
mm = minutes
ss = seconds
cc = centiseconds
1002023 SV A
{ XE TIME }TIME.
The Equipment's current date and time. Format is
described in the variable GEMTIMEFORMAT (VID
1002065). It may be either
YYYYMMDDhhmmsscc OR YYMMDDhhmmss
YY(YY) = year
MM = month
DD = day
hh = hours
mm = minutes
ss = seconds
(cc = centiseconds)
Terminal Service
1002034 EC U1
{ XE WBITS10}WBITS10.
An EC which controls the W-Bit setting used when
sending S10F1.
0 = W-Bit not set
1 = W-Bit set
Data Collection
1002030 SV U4
{ XE PREVIOUSCEID }PREVIOUSCEID.
The CEID of the most recent Collection event which
has occurred.
1002031 EC BOOL
{ XE RPTYPE }RPTYPE.
This EC controls some aspects of the format of Event
Reports sent by this Equipment.
FALSE = Normal Event Reports
TRUE = Annotated Event Reports
1002032 EC U1
{ XE CONFIGEVENTS }CONFIGEVENTS.
An EC which controls some aspects of the Event
Reports sent by this Equipment.
0 = S6F9 or S6F3
1 = S6F11 or S6F13
1002033 EC U1
{ XE WBITS6}WBITS6.
An EC which controls the W-Bit setting used when
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 173 of 241
VID Class Forma
t
Name and Description
sending stream six messages (events, trace)
0 = W-Bit not set
1 = W-Bit set
1002035 SV L
{ XE EVENTSENABLED }EVENTSENABLED.
A list of all Events which are currently enabled.
Format as follows:
<L
<U4 CEID>
...
>
1002036 DV U4
{ XE ECIDCHANGE }ECIDCHANGE.
The VID of the Equipment Constant most recently
changed by the Operator.
Spooling
1002037 EC U4
{ XE MAXSPOOLTRANSMIT
}MAXSPOOLTRANSMIT.
The maximum number of spooled messages the
equipment will send each time the Host reads the
spool. A setting of zero indicates that all spooled
messages should be sent. Refer to the description of
S6F23 in the "SECS Message Detail" section for
further information.
1002038 SV U4
{ XE SPOOLCOUNTACTUAL
}SPOOLCOUNTACTUAL.
A count of the number of messages actually present
on the spool disk, adjusted for any messages which
have been overwritten or otherwise discarded.
1002039 SV U4
{ XE SPOOLCOUNTTOTAL }SPOOLCOUNTTOTAL.
A count of the number of messages the equipment
attempted to write to the spool disk. This number
includes messages actually present on the spool disk,
and also any messages which may have been
overwritten or otherwise discarded.
1002040 SV A[16]
{ XE SPOOLFULLTIME }SPOOLFULLTIME.
The date and time at which the spool file became full.
Format is: YYYYMMDDhhmmsscc. See description
of CLOCK variable above for format details.
1002041 SV U1
{ XE SPOOLLOADSUBSTATE
}SPOOLLOADSUBSTATE.
The current state within the SPOOL LOAD super-
state.
6 = Spool Not Full
