SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 173 of 241
VID Class Forma
t
Name and Description
sending stream six messages (events, trace)
0 = W-Bit not set
1 = W-Bit set
1002035 SV L
{ XE EVENTSENABLED }EVENTSENABLED.
A list of all Events which are currently enabled.
Format as follows:
<L
<U4 CEID>
...
>
1002036 DV U4
{ XE ECIDCHANGE }ECIDCHANGE.
The VID of the Equipment Constant most recently
changed by the Operator.
Spooling
1002037 EC U4
{ XE MAXSPOOLTRANSMIT
}MAXSPOOLTRANSMIT.
The maximum number of spooled messages the
equipment will send each time the Host reads the
spool. A setting of zero indicates that all spooled
messages should be sent. Refer to the description of
S6F23 in the "SECS Message Detail" section for
further information.
1002038 SV U4
{ XE SPOOLCOUNTACTUAL
}SPOOLCOUNTACTUAL.
A count of the number of messages actually present
on the spool disk, adjusted for any messages which
have been overwritten or otherwise discarded.
1002039 SV U4
{ XE SPOOLCOUNTTOTAL }SPOOLCOUNTTOTAL.
A count of the number of messages the equipment
attempted to write to the spool disk. This number
includes messages actually present on the spool disk,
and also any messages which may have been
overwritten or otherwise discarded.
1002040 SV A[16]
{ XE SPOOLFULLTIME }SPOOLFULLTIME.
The date and time at which the spool file became full.
Format is: YYYYMMDDhhmmsscc. See description
of CLOCK variable above for format details.
1002041 SV U1
{ XE SPOOLLOADSUBSTATE
}SPOOLLOADSUBSTATE.
The current state within the SPOOL LOAD super-
state.
6 = Spool Not Full
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 174 of 241 ©Siemens AG, all rights reserved
VID Class Forma
t
Name and Description
7 = Spool Full
1002042 SV A[16]
{ XE SPOOLSTARTTIME }SPOOLSTARTTIME.
The date and time at which the first message was
written to the current spool file. Format is:
YYYYMMDDhhmmsscc.
See description of CLOCK variable above for format
details.
1002043 SV U1
{ XE SPOOLSTATE }SPOOLSTATE.
The current spool state within the POWER ON super-
state.
1 = Spool Inactive
2 = Spool Active
1002044 SV U1
{ XE SPOOLUNLOADSUBSTATE
}SPOOLUNLOADSUBSTATE.
The current spool state within the SPOOL UNLOAD
super-state.
3 = Purge Spool
4 = Transmit Spool
5 = No Spool
1002045 EC U1
{ XE CONFIGSPOOL }CONFIGSPOOL.
This EC determines whether spooling is enabled or
disabled for this Equipment.
0 = Disabled
1 = Enabled
1002046 EC BOOL
{ XE OVERWRITESPOOL }OVERWRITESPOOL.
This EC determines the action to be taken by the
Equipment when the Spool file reaches its capacity.
TRUE = Overwrite Spool
FALSE = Do Not Overwrite Spool
Limit Monitoring
1002047 DV U4
{ XE GEMLIMITSVID }GEMLIMITSVID.
The VID relating to the most recent Limits Monitoring
transition event which occurred.
1002048 DV B[1]
{ XE GEMEVENTLIMIT }GEMEVENTLIMIT.
The LIMITID relating to the most recent Limits
Monitoring transition event which occurred.
1002049 DV B[1]
{ XE GEMTRANSTYPE }GEMTRANSTYPE.
Transition type relating to the most recent Limits
Monitoring transition which occurred.
0x00 = Lower -> Upper
0x01 = Upper -> Lower
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 175 of 241
VID Class Forma
t
Name and Description
1002050 EC U2
{ XE GEMLIMITSTIMER }GEMLIMITSTIMER.
The time in seconds this equipment will pauses
between checking for Limits Monitoring transitions
On-Line Identification
1002051 SV A[6]
{ XE MDLN }MDLN.
Model number. „HSxx„ , „HFx„ , or „Sxx„ ,
„S25HM„
1002052 SV A[6]
{ XE SOFTREV }SOFTREV.
Software revision number. "505.xx"
Miscellaneous
1002054 SV A
{ XE SOFTWAREREVTABLE
}SOFTWAREREVTABLE
Revision of feeder table software
After startup this is the revision number of the first
table. Will be updated with every event
TableDownload (2010008).
1002055 EC U2
{ XE HEARTBEAT }HEARTBEAT.
The time in seconds that the Equipment will pause
before sending S1F1 to test the link. Units are
seconds. Valid values are 0-3200 (a setting of zero
will disable the heartbeat).
1002065 EC U1
{ XE GEMTIMEFORMAT }GEMTIMEFORMAT
Format of TIME (VID 1002023)
0: 12 digits
1: 16 digits (Year 2000 compliant)
1002067 SV A[30]
{ XE SOFTWAREREVGEM }SOFTWAREREVGEM
GEM Software revision number. "505.xx"
1002068 EC A[10]
{ XE NICKNAME }NICKNAME
Default value is "SIPLACE"
Can be overwritten with an individual name for each
machine.
1002069 SV I8
{ XE LASTERRORCODE }LASTERRORCODE
If the General Error Event FM_GENERAL is used,
this Variable contains the Error Code. The Error Code
is identical to the CEID of the specific Error Event.
Example:
A barcode reading error can be reported with the
Event
