SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 174 of 241 ©Siemens AG, all rights reserved
VID Class Forma
t
Name and Description
7 = Spool Full
1002042 SV A[16]
{ XE SPOOLSTARTTIME }SPOOLSTARTTIME.
The date and time at which the first message was
written to the current spool file. Format is:
YYYYMMDDhhmmsscc.
See description of CLOCK variable above for format
details.
1002043 SV U1
{ XE SPOOLSTATE }SPOOLSTATE.
The current spool state within the POWER ON super-
state.
1 = Spool Inactive
2 = Spool Active
1002044 SV U1
{ XE SPOOLUNLOADSUBSTATE
}SPOOLUNLOADSUBSTATE.
The current spool state within the SPOOL UNLOAD
super-state.
3 = Purge Spool
4 = Transmit Spool
5 = No Spool
1002045 EC U1
{ XE CONFIGSPOOL }CONFIGSPOOL.
This EC determines whether spooling is enabled or
disabled for this Equipment.
0 = Disabled
1 = Enabled
1002046 EC BOOL
{ XE OVERWRITESPOOL }OVERWRITESPOOL.
This EC determines the action to be taken by the
Equipment when the Spool file reaches its capacity.
TRUE = Overwrite Spool
FALSE = Do Not Overwrite Spool
Limit Monitoring
1002047 DV U4
{ XE GEMLIMITSVID }GEMLIMITSVID.
The VID relating to the most recent Limits Monitoring
transition event which occurred.
1002048 DV B[1]
{ XE GEMEVENTLIMIT }GEMEVENTLIMIT.
The LIMITID relating to the most recent Limits
Monitoring transition event which occurred.
1002049 DV B[1]
{ XE GEMTRANSTYPE }GEMTRANSTYPE.
Transition type relating to the most recent Limits
Monitoring transition which occurred.
0x00 = Lower -> Upper
0x01 = Upper -> Lower
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 175 of 241
VID Class Forma
t
Name and Description
1002050 EC U2
{ XE GEMLIMITSTIMER }GEMLIMITSTIMER.
The time in seconds this equipment will pauses
between checking for Limits Monitoring transitions
On-Line Identification
1002051 SV A[6]
{ XE MDLN }MDLN.
Model number. „HSxx„ , „HFx„ , or „Sxx„ ,
„S25HM„
1002052 SV A[6]
{ XE SOFTREV }SOFTREV.
Software revision number. "505.xx"
Miscellaneous
1002054 SV A
{ XE SOFTWAREREVTABLE
}SOFTWAREREVTABLE
Revision of feeder table software
After startup this is the revision number of the first
table. Will be updated with every event
TableDownload (2010008).
1002055 EC U2
{ XE HEARTBEAT }HEARTBEAT.
The time in seconds that the Equipment will pause
before sending S1F1 to test the link. Units are
seconds. Valid values are 0-3200 (a setting of zero
will disable the heartbeat).
1002065 EC U1
{ XE GEMTIMEFORMAT }GEMTIMEFORMAT
Format of TIME (VID 1002023)
0: 12 digits
1: 16 digits (Year 2000 compliant)
1002067 SV A[30]
{ XE SOFTWAREREVGEM }SOFTWAREREVGEM
GEM Software revision number. "505.xx"
1002068 EC A[10]
{ XE NICKNAME }NICKNAME
Default value is "SIPLACE"
Can be overwritten with an individual name for each
machine.
1002069 SV I8
{ XE LASTERRORCODE }LASTERRORCODE
If the General Error Event FM_GENERAL is used,
this Variable contains the Error Code. The Error Code
is identical to the CEID of the specific Error Event.
Example:
A barcode reading error can be reported with the
Event
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 176 of 241 ©Siemens AG, all rights reserved
VID Class Forma
t
Name and Description
CEID 920001 FM_LP_BC_NOK
or with the General Error Event
CEID 1001024 FM_GENERAL and the Variables
VID 1002069 LASTERRORCODE = 920001 and
VID 1002070 LASTFMTEXT = "FM_LP_BC_NOK"
1002070 SV A
{ XE LASTFMTEXT }LASTFMTEXT
Error Text of the last specific Error Event. For a
detailed description see LASTERRORCODE
1002071 SV A
{ XE SOFTWAREREVMTC }SOFTWAREREVMTC
Software revision of the Matrix Tray Changer
Only valid after a download of the MTC firmware.
Process Program Management
1002080 SV A
{ XE CURRENTSETUP }CURRENTSETUP
Name of current setup loaded in machine
An empty text indicates an error.
1002081 SV A
FIRST{ XE CURRENTPLACEPROGRAM
}CURRENTPLACEPROGRAM
Name of current placement program loaded in
machine for Processing 1 Area.
This data item will be set when a new Process
Program is downloaded to a SIPLACE machine for
the corresponding processing area and a PCB
reaches the corresponding processing conveyor:
An empty text indicates an error.
1002082 SV A
SECOND{ XE CURRENTPLACEPROGRAM
}CURRENTPLACEPROGRAM
Name of current placement program loaded in
machine for Processing 2 Area.
An empty text indicates an error.
1002942 EC U4
{ XE MAX_TIME_TO_STOP }MAX_TIME_TO_STOP
max. spoolingtime in minutes, if safespoolmode ist
activ
1002943 EC U1
{ XE SAFE_SPOOL_MODE }SAFE_SPOOL_MODE
0 = inactiv
1 = aktiv
GUI
1122001 SV A
{ XE GUIACTIONTEXT }GUIACTIONTEXT
