SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 175 of 241
VID Class Forma
t
Name and Description
1002050 EC U2
{ XE GEMLIMITSTIMER }GEMLIMITSTIMER.
The time in seconds this equipment will pauses
between checking for Limits Monitoring transitions
On-Line Identification
1002051 SV A[6]
{ XE MDLN }MDLN.
Model number. „HSxx„ , „HFx„ , or „Sxx„ ,
„S25HM„
1002052 SV A[6]
{ XE SOFTREV }SOFTREV.
Software revision number. "505.xx"
Miscellaneous
1002054 SV A
{ XE SOFTWAREREVTABLE
}SOFTWAREREVTABLE
Revision of feeder table software
After startup this is the revision number of the first
table. Will be updated with every event
TableDownload (2010008).
1002055 EC U2
{ XE HEARTBEAT }HEARTBEAT.
The time in seconds that the Equipment will pause
before sending S1F1 to test the link. Units are
seconds. Valid values are 0-3200 (a setting of zero
will disable the heartbeat).
1002065 EC U1
{ XE GEMTIMEFORMAT }GEMTIMEFORMAT
Format of TIME (VID 1002023)
0: 12 digits
1: 16 digits (Year 2000 compliant)
1002067 SV A[30]
{ XE SOFTWAREREVGEM }SOFTWAREREVGEM
GEM Software revision number. "505.xx"
1002068 EC A[10]
{ XE NICKNAME }NICKNAME
Default value is "SIPLACE"
Can be overwritten with an individual name for each
machine.
1002069 SV I8
{ XE LASTERRORCODE }LASTERRORCODE
If the General Error Event FM_GENERAL is used,
this Variable contains the Error Code. The Error Code
is identical to the CEID of the specific Error Event.
Example:
A barcode reading error can be reported with the
Event
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 176 of 241 ©Siemens AG, all rights reserved
VID Class Forma
t
Name and Description
CEID 920001 FM_LP_BC_NOK
or with the General Error Event
CEID 1001024 FM_GENERAL and the Variables
VID 1002069 LASTERRORCODE = 920001 and
VID 1002070 LASTFMTEXT = "FM_LP_BC_NOK"
1002070 SV A
{ XE LASTFMTEXT }LASTFMTEXT
Error Text of the last specific Error Event. For a
detailed description see LASTERRORCODE
1002071 SV A
{ XE SOFTWAREREVMTC }SOFTWAREREVMTC
Software revision of the Matrix Tray Changer
Only valid after a download of the MTC firmware.
Process Program Management
1002080 SV A
{ XE CURRENTSETUP }CURRENTSETUP
Name of current setup loaded in machine
An empty text indicates an error.
1002081 SV A
FIRST{ XE CURRENTPLACEPROGRAM
}CURRENTPLACEPROGRAM
Name of current placement program loaded in
machine for Processing 1 Area.
This data item will be set when a new Process
Program is downloaded to a SIPLACE machine for
the corresponding processing area and a PCB
reaches the corresponding processing conveyor:
An empty text indicates an error.
1002082 SV A
SECOND{ XE CURRENTPLACEPROGRAM
}CURRENTPLACEPROGRAM
Name of current placement program loaded in
machine for Processing 2 Area.
An empty text indicates an error.
1002942 EC U4
{ XE MAX_TIME_TO_STOP }MAX_TIME_TO_STOP
max. spoolingtime in minutes, if safespoolmode ist
activ
1002943 EC U1
{ XE SAFE_SPOOL_MODE }SAFE_SPOOL_MODE
0 = inactiv
1 = aktiv
GUI
1122001 SV A
{ XE GUIACTIONTEXT }GUIACTIONTEXT
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 177 of 241
VID Class Forma
t
Name and Description
Last „Action text“ sent to GUI
An empty text indicates an error
1122002 SV A
GUISTATETEXT { XE GUISTATETEXT }
Last „State text“ sent to GUI
An empty text indicates an error
1122007 SV U4
{ XE GUIMESSAGENUMBER
}GUIMESSAGENUMBER
Used for General GUI Events CEID 1120300 and
1120301
Contains the CEID of the special GUI Event.
E.g. in case of GUIStart you may use either Event
1120007 GUIStart or Event MessageFromGuiGeneral
with VID 1122007 (GUIMESSAGENUMBER) which
will contain the value 1120007.
13xxxxx
14xxxxx
23xxxxx
24xxxxx
SIPLACE Head 1
SIPLACE Head 2
SIPLACE Head 3
SIPLACE Head 4
1312001
1412001
2312001
2412001
SV I4
{ XE HEIGHTHEADx }HEIGHTHEAD1
HEIGHTHEAD2
HEIGHTHEAD3
HEIGHTHEAD4
Height of placement head x.
Only valid after reference run. Units are 1/1000 mm
During the reference run the SIPLACE measures the
distance between the upper edge of the conveyor belt
and the nozzle on segment 1. The HEIGHTHEADx is
then calculated by subtracting the length of the nozzle
on segment 1 from the measured value. The nozzle
length is defined in the machine data. So
HEIGHTHEADx is a relative not an absolute value.
A value of 0 indicates an error
1312002
1412002
2312002
2412002
SV L
{ XE GANTRYINFOx}GANTRYINFO1
GANTRYINFO2
GANTRYINFO3
GANTRYINFO4
Gantry information for head 1. The data is
automatically reseted when a PCB reaches the
corresponding processing conveyor.
<L
