SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual

VID Class Forma

Name and Description

<F8 Angle> [1/100 degrees]

<U1 Quality> [0 - 100]

<U4 Length> [1/1000 mm]

<U4 Width> [1/1000 mm]

....

<F8 OrthoDev> [degrees]

.....

<U4 X-position>, <U4 Y-position>, <F8 Angle> and

<I4 Vacuum> are not valid for TwinHead

The first element in this list refers to segment 1, the

second to segment 2 and so on. If a segment was not

in use in the last placement cycle the list for that

segment is left empty

For a detailed description of the data item see „4.2

Data Item Dictionary“.

An empty list indicates an error.

1312004

1412004

2312004

2412004

SV L

{ XE PICKUPINFOx}PICKUPINFO1

PICKUPINFO2

PICKUPINFO3

PICKUPINFO4

Pick-up information for head x.

SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual

VID Class Forma

Name and Description

<I4 PickUpVacuum> [mbar]

....

<I4 Vacuum> is not valid for TwinHead

The first element in this list refers to segment 1, the

second to segment 2 and so on. If a segment was not

in use in the last pick up cycle the list for that segment

is left empty.

If the component was picked up from a feeder Level

will contain -1.

In the case that the component was picked up from a

tray in the matrix tray changer TrackNumber will

contain the tower of the MTC(1,2). In this way

PICKIPINFOx has the same format as in previous

versions.

For a detailed description of the data item see „4.2

Data Item Dictionary“.

An empty list indicates an error.

1312005

1412005

2312005

2412005

SV L

{ XE NOZZLECONF1}NOZZLECONF1

NOZZLECONF2

NOZZLECONF3

NOZZLECONF4

Nozzle configuration on head x. Only valid after

reference run.

<I4 REAL_NOZZLE_LENGTH> [1/1000

mm]

......

The nozzle length is measured during the reference

run. It depends on the HEIGHTHEADx value. So

REAL_NOZZLE_LENGTH is not a absolute but a

relative value.

SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual

VID Class Forma

Name and Description

It is calculated by subtracting the measured distance

between the nozzle and the upper edge of the

transport conveyor from the HEIGHTHEADx value.

An empty list indicates an error.

For a detailed description of the data item see „4.2

Data Item Dictionary“.

1312006

1412006

2312006

2412006

SV L

{ XE VACUUMDATAx}VACUUMDATA1

VACUUMDATA2

VACUUMDATA3

VACUUMDATA4

Vacuum measurements from the last reference run on

head x. Valid only after reference run.

<I4 open_nozzle> [mbar]

<I4 closed_nozzle> [mbar]

<I4 cubic_nozzle> [mbar]

<I4 not_cubic_nozzle> [mbar]

<I4 tol_dirty_nozzle> [mbar]

<I4 tol_leaky_nozzle> [mbar]

.....

<I4 closed_nozzle> is not valid for TwinHead

The first element in this list refers to segment 1, the

second to segment 2, and so on.

tol_dirty_nozzle and tol_leaky_nozzle are currently

not used.

An empty list indicates an error.

For a detailed description of the data item see „4.2

Data Item Dictionary“.

1312007

1412007

2312007

2412007

SV L

{ XE SEGMENTINFOx}SEGMENTINFO1

SEGMENTINFO2

SEGMENTINFO3

SEGMENTINFO4

Summation of information per segment.
