SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 183 of 241
VID Class Forma
t
Name and Description
<F8 MaxLeadDev>
<F8 MaxBallDev>
>
....
(for each segment)
... .
>
<U4 X-position>, <U4 Y-position> and <F8 Angle>
are not valid for TwinHead
The first element in this list refers to segment 1, the
second to segment 2 and so on. If a segment was not
in use in the last placement cycle the list for that
segment is left empty.
Miscellaneous
2012013 SV U2
{ XE ERRORTYPE }ERRORTYPE
Type of the most recent error
2 Transport
3 Track error
4 Machine error
5 Miscellaneous
A value of 0 indicates an error.
2012014 SV U2
{ XE GANRTYONERROR }GANTRYONERROR
Gantry associated with the most recent error (1...4)
A value of 0 indicates an error.
2012015 SV U2
{ XE SEGMENTONERROR }SEGMENTONERROR
Segment number associated with the most recent
error (1...12)
A value of 0 indicates an error.
2012016 SV U2
{ XE TRACKONERROR }TRACKONERROR
Track number associated with the most recent error
event
A value of 0 indicates an error.
2012017 SV U2
{ XE ERRORINFO1}ERRORINFO1
Additional information about an error event.
Corresponds to the first parameter of an error
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 184 of 241 ©Siemens AG, all rights reserved
VID Class Forma
t
Name and Description
message on the station computer.
2012018 SV U2
{ XE ERRORINFO2}ERRORINFO2
Additional information about an error event.
Corresponds to the second parameter of an error
message on the station computer.
2012021 SV L
GANTRYHEADCONFIG { XE
GANTRYHEADCONFIG}
<L
<L
<I2 GantryGroupID
<L
<L
<I2 GantryID>
<I2 TypeOfGantry>
<L
<L
<I2 HeadID>
<I2 HEADTYPE>
>
...
>
>
...
>
>
TypeOfGantry:
At the moment there is only 1 Type of Gantry.
TypeOfGantry is always = 1
HEADTYPE:
4 = TwinHead with 2 nozzles
5 = Revolverhead with 12 nozzles
6 = Revolverhead with 6 nozzles
7 = IC Head
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012022 DV U1
{ XE MACHINESIDE }MACHINESIDE
For a detailed description of the data item see „4.2
Data Item Dictionary“.
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 185 of 241
VID Class Forma
t
Name and Description
2012023 DV I2
{ XE TRACKNUMBER }TRACKNUMBER
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012024 DV I2
{ XE DIVISION }DIVISION
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012025 DV I2
{ XE LEVEL }LEVEL
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012026 DV U1
{ XE SEGMENT }SEGMENT
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012027 DV A
{ XE COMPONENTNAME }COMPONENTNAME
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012028 DV U2
{ XE GANTRYID }GANTRYID
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012029 DV U2
{ XE GANTRYGROUPID }GANTRYGROUPID
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012030 DV U2
{ XE HEADID }HEADID
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012031 DV A
{ XE REFERENCEDESIGNATOR
}REFERENCEDESIGNATOR
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012032 DV U2
{ XE PACKAGEFORMNUMBER
}PACKAGEFORMNUMBER
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012033 DV U2
{ XE PLACEERRORDESCRIPTION
}PLACEERRORDESCRIPTION
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012035 DV U1
{ XE LOCATION }LOCATION
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012037 SV L
{ XE PICKUPERRORS }PICKUPERRORSLOC1
Pick-Up Errors of location 1 (see 1.6 machine areas).
This data item will be reset when a new Process
Program is downloaded to a SIPLACE machine for
