S I P L A C E G EM S W V e r s i on G EM 505 . 03 SP 1 H O S T I n t e r f a c e M anua l ©S i e m en s A G, a ll r i gh t s r e s e r v ed page 185 o f 241 V I D C l ass Fo rma t Name a nd Descr ip t ion 2012023 D V I 2…
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 184 of 241 ©Siemens AG, all rights reserved
VID Class Forma
t
Name and Description
message on the station computer.
2012018 SV U2
{ XE ERRORINFO2}ERRORINFO2
Additional information about an error event.
Corresponds to the second parameter of an error
message on the station computer.
2012021 SV L
GANTRYHEADCONFIG { XE
GANTRYHEADCONFIG}
<L
<L
<I2 GantryGroupID
<L
<L
<I2 GantryID>
<I2 TypeOfGantry>
<L
<L
<I2 HeadID>
<I2 HEADTYPE>
>
...
>
>
...
>
>
TypeOfGantry:
At the moment there is only 1 Type of Gantry.
TypeOfGantry is always = 1
HEADTYPE:
4 = TwinHead with 2 nozzles
5 = Revolverhead with 12 nozzles
6 = Revolverhead with 6 nozzles
7 = IC Head
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012022 DV U1
{ XE MACHINESIDE }MACHINESIDE
For a detailed description of the data item see „4.2
Data Item Dictionary“.
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 185 of 241
VID Class Forma
t
Name and Description
2012023 DV I2
{ XE TRACKNUMBER }TRACKNUMBER
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012024 DV I2
{ XE DIVISION }DIVISION
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012025 DV I2
{ XE LEVEL }LEVEL
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012026 DV U1
{ XE SEGMENT }SEGMENT
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012027 DV A
{ XE COMPONENTNAME }COMPONENTNAME
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012028 DV U2
{ XE GANTRYID }GANTRYID
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012029 DV U2
{ XE GANTRYGROUPID }GANTRYGROUPID
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012030 DV U2
{ XE HEADID }HEADID
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012031 DV A
{ XE REFERENCEDESIGNATOR
}REFERENCEDESIGNATOR
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012032 DV U2
{ XE PACKAGEFORMNUMBER
}PACKAGEFORMNUMBER
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012033 DV U2
{ XE PLACEERRORDESCRIPTION
}PLACEERRORDESCRIPTION
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012035 DV U1
{ XE LOCATION }LOCATION
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012037 SV L
{ XE PICKUPERRORS }PICKUPERRORSLOC1
Pick-Up Errors of location 1 (see 1.6 machine areas).
This data item will be reset when a new Process
Program is downloaded to a SIPLACE machine for
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 186 of 241 ©Siemens AG, all rights reserved
VID Class Forma
t
Name and Description
the corresponding processing area and a PCB
reaches the corresponding processing conveyor:
processing 1 area (S25)
processing 1 area (HS50)
processing 1 area (HF).
<L
<L
<A ComponentName>
<I2 TrackNumber>
<U2 FeederType>
<I2 Level>
<I2 Division>
<U1 Tower>
<U2 FeederAccessesPerPCB>
<U2 VacuumErrors>
<U2 OpticalErrors>
<U2 CoplanarityErrors>
>
....
>
FeederAccessesPerPCB will be reset when a PCB
reaches the corresponding processing conveyor.
If the component was picked up from a feeder Level
and Tower will contain -1.
In the case that the component was picked up from a
tray in the matrix tray changer TrackNumber will be -1
and Level and Tower are valid.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
2012038 SV L
{ XE PICKUPERRORS }PICKUPERRORSLOC2
Pick-Up Errors of location 2 (see 1.6 machine areas).
This data item will be reset when a new Process
Program is downloaded to a SIPLACE machine for
the corresponding processing area and a PCB
reaches the corresponding processing conveyor:
processing 1 area (S25)
processing 2 area (HS50)
processing 2 area (HF).
<L
