SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 187 of 241
VID Class Forma
t
Name and Description
<L
<A ComponentName>
<I2 TrackNumber>
<U2 FeederType>
<I2 Level>
<I2 Division>
<U1 Tower>
<U2 FeederAccessesPerPCB>
<U2 VacuumErrors>
<U2 OpticalErrors>
<U2 CoplanarityErrors>
>
....
>
FeederAccessesPerPCB will be reset when a PCB
reaches the corresponding processing conveyor.
If the component was picked up from a feeder Level
and Tower will contain -1.
In the case that the component was picked up from a
tray in the matrix tray changer TrackNumber will be -1
and Level and Tower are valid.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
2012039 SV L
{ XE PICKUPERRORS }PICKUPERRORSLOC3
Pick-Up Errors of location 3 (see 1.6 machine areas).
This data item will be reset when a new Process
Program is downloaded to a SIPLACE machine for
the corresponding processing area and a PCB
reaches the corresponding processing conveyor:
processing 1 area (S25)
processing 2 area (HS50)
processing 2 area (HF).
<L
<L
<A ComponentName>
<I2 TrackNumber>
<U2 FeederType>
<I2 Level>
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 188 of 241 ©Siemens AG, all rights reserved
VID Class Forma
t
Name and Description
<I2 Division>
<U1 Tower>
<U2 FeederAccessesPerPCB>
<U2 VacuumErrors>
<U2 OpticalErrors>
<U2 CoplanarityErrors>
>
....
>
FeederAccessesPerPCB will be reset when a PCB
reaches the corresponding processing conveyor.
If the component was picked up from a feeder Level
and Tower will contain -1.
In the case that the component was picked up from a
tray in the matrix tray changer TrackNumber will be -1
and Level and Tower are valid.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
2012040 SV L
{ XE PICKUPERRORS }PICKUPERRORSLOC4
Pick-Up Errors of location 4 (see 1.6 machine areas).
This data item will be reset when a new Process
Program is downloaded to a SIPLACE machine for
the corresponding processing area and a PCB
reaches the corresponding processing conveyor:
processing 1 area (S25)
processing 1 area (HS50)
processing 1 area (HF).
<L
<L
<A ComponentName>
<I2 TrackNumber>
<U2 FeederType>
<I2 Level>
<I2 Division>
<U1 Tower>
<U2 FeederAccessesPerPCB>
<U2 VacuumErrors>
<U2 OpticalErrors>
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 189 of 241
VID Class Forma
t
Name and Description
<U2 CoplanarityErrors>
>
....
>
FeederAccessesPerPCB will be reset when a PCB
reaches the corresponding processing conveyor.
If the component was picked up from a feeder Level
and Tower will contain -1.
In the case that the component was picked up from a
tray in the matrix tray changer TrackNumber will be -1
and Level and Tower are valid.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
2012041 SV A
{ XE PICKUPDATARESETPOINT
}PICKUPDATARESETPOINTLOC1
Date and time when the „Pick-Up Error“ data item of
Location 1 was reset.
An empty text indicates an error.
2012042 SV A
{ XE PICKUPDATARESETPOINT
}PICKUPDATARESETPOINTLOC2
Date and time when the „Pick-Up Error“ data item of
Location 2 was reset.
An empty text indicates an error.
2012043 SV A
{ XE PICKUPDATARESETPOINT
}PICKUPDATARESETPOINTLOC3
Date and time when the „Pick-Up Error“ data item of
Location 3 was reset.
An empty text indicates an error.
2012044 SV A
{ XE PICKUPDATARESETPOINT
}PICKUPDATARESETPOINTLOC4
Date and time when the „Pick-Up Error“ data item of
Location 4 was reset.
An empty text indicates an error.
2012046 DV L TAPE_INFO
<L
<A ComponentName>
<A CompBarcode1>
<A CompBarcode2>
<A CompBarcode3>
<A CompBarcode4>
