SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 189 of 241
VID Class Forma
t
Name and Description
<U2 CoplanarityErrors>
>
....
>
FeederAccessesPerPCB will be reset when a PCB
reaches the corresponding processing conveyor.
If the component was picked up from a feeder Level
and Tower will contain -1.
In the case that the component was picked up from a
tray in the matrix tray changer TrackNumber will be -1
and Level and Tower are valid.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
2012041 SV A
{ XE PICKUPDATARESETPOINT
}PICKUPDATARESETPOINTLOC1
Date and time when the „Pick-Up Error“ data item of
Location 1 was reset.
An empty text indicates an error.
2012042 SV A
{ XE PICKUPDATARESETPOINT
}PICKUPDATARESETPOINTLOC2
Date and time when the „Pick-Up Error“ data item of
Location 2 was reset.
An empty text indicates an error.
2012043 SV A
{ XE PICKUPDATARESETPOINT
}PICKUPDATARESETPOINTLOC3
Date and time when the „Pick-Up Error“ data item of
Location 3 was reset.
An empty text indicates an error.
2012044 SV A
{ XE PICKUPDATARESETPOINT
}PICKUPDATARESETPOINTLOC4
Date and time when the „Pick-Up Error“ data item of
Location 4 was reset.
An empty text indicates an error.
2012046 DV L TAPE_INFO
<L
<A ComponentName>
<A CompBarcode1>
<A CompBarcode2>
<A CompBarcode3>
<A CompBarcode4>
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 190 of 241 ©Siemens AG, all rights reserved
VID Class Forma
t
Name and Description
<A CompBarcode5>
<A CompBarcode6>
<U4 CompContainerSize>
>
Barcode information of a tape. Used for traceability.
2012047 DV A TABLE_ID
<A Table Barcode>
ID of a table scanned by the operator
2012048 DV U1 TOWER_ID
<U1 Tower Number>
Traceability
2512001 DV L TRACE_PCB_DATA
<L
<A JobName>
<A PCBBarcode>
<A ClusterName>
<A Setup>
<A ProdTimeStart>
<A ProdTimeEnd>
<U1 Errorcode>
>
Traceability data for the actual PCB
2512002 DV L TRACE_ALL_COMPONENTS
<L
<U4 Reference>
<L
<A ComponentName>
<A CompBarcode1>
<A CompBarcode2>
<A CompBarcode3>
<A CompBarcode4>
<A CompBarcode5>
<A CompBarcode6>
<U1 CompChanged>
>
....
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 191 of 241
VID Class Forma
t
Name and Description
>
Each reference represents one component batch used
for the actual pcb.
See also TRACE_SINGLE_CIRCUIT
2512003 DV L TRACE_SINGLE_CIRCUIT
<L
<A SingleCircuitName>
<L
<U4 Reference>
<U4 Reference>
...
>
...
(for each singlecircuit)
>
One reference refers to one reference in
TRACE_ALL_COMPONENTS
