SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 190 of 241 ©Siemens AG, all rights reserved
VID Class Forma
t
Name and Description
<A CompBarcode5>
<A CompBarcode6>
<U4 CompContainerSize>
>
Barcode information of a tape. Used for traceability.
2012047 DV A TABLE_ID
<A Table Barcode>
ID of a table scanned by the operator
2012048 DV U1 TOWER_ID
<U1 Tower Number>
Traceability
2512001 DV L TRACE_PCB_DATA
<L
<A JobName>
<A PCBBarcode>
<A ClusterName>
<A Setup>
<A ProdTimeStart>
<A ProdTimeEnd>
<U1 Errorcode>
>
Traceability data for the actual PCB
2512002 DV L TRACE_ALL_COMPONENTS
<L
<U4 Reference>
<L
<A ComponentName>
<A CompBarcode1>
<A CompBarcode2>
<A CompBarcode3>
<A CompBarcode4>
<A CompBarcode5>
<A CompBarcode6>
<U1 CompChanged>
>
....
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 191 of 241
VID Class Forma
t
Name and Description
>
Each reference represents one component batch used
for the actual pcb.
See also TRACE_SINGLE_CIRCUIT
2512003 DV L TRACE_SINGLE_CIRCUIT
<L
<A SingleCircuitName>
<L
<U4 Reference>
<U4 Reference>
...
>
...
(for each singlecircuit)
>
One reference refers to one reference in
TRACE_ALL_COMPONENTS
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 192 of 241 ©Siemens AG, all rights reserved
7 Predefined Reports
RPTID Name VIDs
0 Clock 1002022<CLOCK>
1 Name and Clock , 1002022<CLOCK>,
1002001<GEMEVENTTEXT>
2 Not used
3 Not used
4 Transport 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
612007<TRANSPORTWIDTH>, 612008
<TWINTRANSPORTWIDTH>
5 PlaceHead1 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1312003< PLACEINFO1>
6 PlaceHead2 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1412003< PLACEINFO2>
7 Not used
8 PickHead1 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1312004< PICKUPINFO1>
9 PickHead2 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1412004< PICKUPINFO2>
10 Not used
11 Not used
12 Not used
13 Fiducial 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
412002< FIDUCIALDATA>, 2012029
<GANTRYGROUPID>, 2012028<GANTRYID>,
2012030<HEADID>,
14 Nozzle1 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1312005< NOZZLECONF1>
15 Nozzle2 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1412005< NOZZLECONF2>
16 Not used
17 Not used
18 Not used
19 RefRunHead1 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1312001< HEIGHTHEAD1>
20 RefRunHead2 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1412001< HEIGHTHEAD2>
21 RefRunVac1 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1312006< VACUUMDATA1>
22 RefRunVac2 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1412006 <VACUUMDATA2>
23 Firmware 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1002054< SOFTWAREREVTABLE>,
