SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 193 of 241
RPTID Name VIDs
1002071<SOFTWAREREVMTC>
24 Barcode 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
912002< BCININPUTCONVEYOR>,
912005<PCBSIDEININPUTCONVEYOR>
25 Not used
26 Not used
27 BeBarcode 1002001<GEMEVENTTEXT>,
1002022<CLOCK>,
912003<COMPONENTBARCODE>,
912004<WAYOFINPUTCOMPONENTBARCODE
>, 2012035<LOCATION>,
2012023<TRACKNUMBER>,
2012024<DIVISION>, 2012025<LEVEL>,
2012046<TAPE_INFO>,
28 PickupError 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
2012026<SEGMENT>,
2012027<COMPONENTNAME>,
2012035<LOCATION>,
2012023<TRACKNUMBER>,
2012024<DIVISION>, 2012025<LEVEL>,
2012028<GANTRYID>,
2012029<GANTRYGROUPID>,
2012030<HEADID>
29 PlaceError 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
2012026<SEGMENT>,
2012031<REFERENCEDESIGNATOR>,
2012027<COMPONENTNAME>,
2012028<GANTRYID>,
2012029<GANTRYGROUPID>,
2012030<HEADID>
2012032<PACKAGEFORMNUMBER>,
2012033<PLACEERRORDESCRIPTION>
30 BarcodeTwin 1002022<CLOCK>, 1002022<CLOCK>,
912012<BCINTWININPUTCONVEYOR>,
912015<PCBSIDEINTWININPUTCONVEYOR>
31 GantryInfoArea1 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1312002<GANTRYINFO1>,
2412002<GANTRYINFO4>
32 GantryInfoArea2 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1412002<GANTRYINFO2>,
2312002<GANTRYINFO3>
33 PlaceHead3 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
2312003< PLACEINFO3>
34 PlaceHead4 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
2412003< PLACEINFO4>
35 Nozzle3 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
2312005< NOZZLECONF3>
36 Nozzle4 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
2412005< NOZZLECONF4>
37 RefRunHead3 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 194 of 241 ©Siemens AG, all rights reserved
RPTID Name VIDs
2312001< HEIGHTHEAD3>
38 RefRunHead4 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
2412001< HEIGHTHEAD4>
39 RefRunVac3 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
2312006< VACUUMDATA3>
40 RefRunVac4 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
2412006 <VACUUMDATA4>
41 MTCInfo 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
812002 <MTCINFO>
42 PickHead3 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
2312004< PICKUPINFO3>
43 PickHead4 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
2412004< PICKUPINFO4>
44 Errorinfo 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1002069<LASTERROR_CODE>, 1002070
<LASTERRORTEXT>
45 GuiMessage 1002001<GEMEVENTTEXT>,
1002022<CLOCK>,
1122007<GUIMESSAGENUMBER>
46 TraceData 1002001<GEMEVENTTEXT>,
1002022<CLOCK>,
2512001<TRACE_PCB_DATA>,
2512002<TRACE_ALL_COMPONENTS>,
2512003<TRACE_SINGLE_CIRCUIT>
47 SpliceDetect 1002001<GEMEVENTTEXT>,
1002022<CLOCK, 2012047<TABLE_ID>,
2012035<LOCATION>,
2012023<TRACKNUMBER>,
2012024<DIVISION>, 2012025<LEVEL>
Report numbers 1000 - 1100 are reserved for internal use.
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 195 of 241
8 Collection Events
8.1 Error Messages as Error Events
Error Messages are reported to the GEM HOST as Error Events (the event name begins
with FM_ ). There are Single Events for each Error Message and a Joint Error
(FM_GENERAL, CEID 1001024) for all Error Messages that is accompanied by the CEID
of the Single Event as the Error Code. The user can use the enable/disable mechanism
to select a display type. Use of the FM_GENERAL is recommended for new HOST
applications.
In contrast to the GEM Interface of SIPLACE S20/S23/F4 machines, the special Error
Events (Event Name : FM_…) feature no predefined report. The General Error Event
FM_GENERAL (CEID 1001024) is made available with a predefined report.
8.2 Description of the Event
Software
CEID Name Description
111001
FM_SC_RECV
Error during RMOS System Call
RECV*
111002
FM_SC_DALOC
Error during RMOS System Call
DALOC*
111003
FM_SC_ALOC
Error during RMOS System Call
ALOC*
111004
FM_SC_LOOK
Error during RMOS System Call
LOOK*
111005
FM_SC_RIO
Error during RMOS System Call
RIO*
111006
FM_DATEN_UNBEK_MELD
Unknown data code in MC1 during
data exchange*
111008
FM_CRUN_MALLOC
Error during RMOS System Call
MALLOC*
111017
FM_SWITCH_DEFAULT
Error in default branch*
111018
FM_SW_FALSCHE_F_NR
MC has received wrong error
number*
111019
FM_PW_SP_ABLAUF_NOK
Error during execution of head
nozzle-check*
111020
FM_OPT_INDEX
Data error in MC: optical centering
indices incorrect*
111055
GEM_UNDEF_FEHLER
error not defined for GEM interface
111056
FM_SW_PIP_OFF
Reading of Nozzle offset not
possible*
111057
FM_SYS_INIT
Initialization of software resources
not correct*
111059
FM_GEM_UNBEK_MELD
Unknown message from SC to GEM
computer*
111064
FM_PDV_DAT_RES
Error upon reserving data for GEM*
111065
FM_PDV_NO_DATA
GEM datum not found*
