SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual

RPTID Name VIDs

2312001< HEIGHTHEAD3>

38 RefRunHead4 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,

2412001< HEIGHTHEAD4>

39 RefRunVac3 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,

2312006< VACUUMDATA3>

40 RefRunVac4 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,

2412006 <VACUUMDATA4>

41 MTCInfo 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,

812002 <MTCINFO>

42 PickHead3 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,

2312004< PICKUPINFO3>

43 PickHead4 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,

2412004< PICKUPINFO4>

44 Errorinfo 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,

1002069<LASTERROR_CODE>, 1002070

45 GuiMessage 1002001<GEMEVENTTEXT>,

1002022<CLOCK>,

1122007<GUIMESSAGENUMBER>

46 TraceData 1002001<GEMEVENTTEXT>,

1002022<CLOCK>,

2512001<TRACE_PCB_DATA>,

2512002<TRACE_ALL_COMPONENTS>,

2512003<TRACE_SINGLE_CIRCUIT>

47 SpliceDetect 1002001<GEMEVENTTEXT>,

1002022<CLOCK, 2012047<TABLE_ID>,

2012035<LOCATION>,

2012023<TRACKNUMBER>,

2012024<DIVISION>, 2012025<LEVEL>

Report numbers 1000 - 1100 are reserved for internal use.

SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual

8 Collection Events

8.1 Error Messages as Error Events

Error Messages are reported to the GEM HOST as Error Events (the event name begins

with FM_ ). There are Single Events for each Error Message and a Joint Error

(FM_GENERAL, CEID 1001024) for all Error Messages that is accompanied by the CEID

of the Single Event as the Error Code. The user can use the enable/disable mechanism

to select a display type. Use of the FM_GENERAL is recommended for new HOST

applications.

In contrast to the GEM Interface of SIPLACE S20/S23/F4 machines, the special Error

Events (Event Name : FM_…) feature no predefined report. The General Error Event

FM_GENERAL (CEID 1001024) is made available with a predefined report.

8.2 Description of the Event

Software

CEID Name Description

111001

FM_SC_RECV

Error during RMOS System Call

RECV*

111002

FM_SC_DALOC

Error during RMOS System Call

DALOC*

111003

FM_SC_ALOC

Error during RMOS System Call

ALOC*

111004

FM_SC_LOOK

Error during RMOS System Call

LOOK*

111005

FM_SC_RIO

Error during RMOS System Call

RIO*

111006

FM_DATEN_UNBEK_MELD

Unknown data code in MC1 during

data exchange*

111008

FM_CRUN_MALLOC

Error during RMOS System Call

MALLOC*

111017

FM_SWITCH_DEFAULT

Error in default branch*

111018

FM_SW_FALSCHE_F_NR

MC has received wrong error

number*

111019

FM_PW_SP_ABLAUF_NOK

Error during execution of head

nozzle-check*

111020

FM_OPT_INDEX

Data error in MC: optical centering

indices incorrect*

111055

GEM_UNDEF_FEHLER

error not defined for GEM interface

111056

FM_SW_PIP_OFF

Reading of Nozzle offset not

possible*

111057

FM_SYS_INIT

Initialization of software resources

not correct*

111059

FM_GEM_UNBEK_MELD

Unknown message from SC to GEM

computer*

111064

FM_PDV_DAT_RES

Error upon reserving data for GEM*

111065

FM_PDV_NO_DATA

GEM datum not found*

SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual

111066

FM_PDV_UNBEK_FHL

Unknown error number from GEM

process data management*

111073

FM_MAPP_11_MA

MAPP_11.MA file missing or faulty*

111074

FM_MAPP_12_MA

MAPP_12.MA file missing or faulty*

111075

FM_MAPP_21_MA

MAPP_21.MA file missing or faulty*

111076

FM_MAPP_22_MA

MAPP_22.MA file missing or faulty*

111078

FM_CONFIG_MA

KONFIG.MA file missing or faulty*

111079

FM_X_PROG_SPUR

X-pick-up position out of travel

range*

111080

FM_Y_PROG_SPUR

Y-pick-up position out of travel

range*

111081

FM_SONST_SPURLEER

Track empty due to exceeding the

travel range or wrong allocation of

nozzles*

111082

FM_SV_SW_FEHLER

Error in placement sequence

software*

111083

FM_BEST_EBENE

Placement sequence error in PCB

data*

111085

FM_SW_VAK_SCAN_MA

file SCANPARA.MA incorrect or

missing*

111086

FM_SW_VAKUUM_MA

file VAKUUM.MA incorrect or

missing*

111089

FM_HOEH_PIP_ZUVIEL

Unknown nozzle at segment, none

specified in configuration*

111090

FM_BLASDRUCK_ZU_GERING

RV head: Air kiss pressure during

placement too low*

111091

FM_BLASDRUCK_ZU_HOCH

RV head: Air kiss pressure during

placement too high*

111093

FM_MAP_MESSD_FEHLT

MP_MESS.DAT mapping file not

available*

111094

FM_MAP_MESSD_NR_FALSCH

Faulty number in MP_MESS.DAT

mapping file*

111095

FM_MAP_MESSD_INDEX

Bad access to MP_MESS.DAT file*

111096

FM_MAP_DAT_KOMM

Task mapping data:

communications error*

111097

FM_GND_FHL_ART_UNBEK

Unknown error in head basic

function

111098

FM_TSP_LP_OBJEKT

Fatal error while creating PCB

object

111099

FM_IPC_KOMM

Faulty LAN communication (IPC)

111100

FM_SW_VAK_Z_MA

VAK_Z.MA file not available or

faulty

111101

FM_GUI_TEXT_MA_ERR_IN_

DYN_LIST

System error (ERR_IN_DYN_LIST)

111102

FM_GUI_TEXT_MA_ERR_NOT_

System error
