SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual

CEID Name Description

511063 FM_OPT_DIM_B_TOL_DEF Component width outside tolerance*

511064 FM_OPT_DIM_B_TOL_S Component width outside tolerance

(s) *

511065 FM_OPT_DIM_B_TOL_R Component width outside tolerance

(r) *

511066 FM_OPT_DIM_B_TOL_C Component width outside tolerance

511067 FM_OPT_DIM_B_TOL_L Component width outside tolerance

(l) *

511068 FM_OPT_DIM_B_TOL_G Component width outside tolerance

(g) *

511069 FM_OPT_DIM_B_TOL_B Component width outside tolerance

(b) *

511070 FM_OPT_BEIN_ANZAHL_DEF Number of pins on component not

correct*

511071 FM_OPT_BEIN_ANZAHL_C Number of pins on component not

correct(c) *

511072 FM_OPT_BEIN_ANZAHL_L Number of pins on component not

correct(l) *

511073 FM_OPT_ORTHOGONALITAE

T_DEF

Orthogonality error during component

meas. *

511074

FM_OPT_ORTHOGONALITAET_C

Orthogonality error during cmpt.

meas. (c) *

511075

FM_OPT_ORTHOGONALITAET_L

Orthogonality error during cmpt.

meas. (l) *

511076

FM_OPT_WINKEL_FEHLER_DEF

Component angle outside tolerance*

511077 FM_OPT_WINKEL_FEHLER_S Component angle outside tolerance

(s) *

511078 FM_OPT_WINKEL_FEHLER_R

Component angle outside tolerance

(r) *

511079 FM_OPT_WINKEL_FEHLER_C

Component angle outside tolerance

511080 FM_OPT_WINKEL_FEHLER_L Component angle outside tolerance

(l) *

511081 FM_OPT_WINKEL_FEHLER_G

Component angle outside tolerance

(g) *

511082 FM_OPT_WINKEL_FEHLER_B Component angle outside tolerance

(b) *

511083 FM_OPT_POS_NK_DEF Position: component outside feed

tolerance*

511084 FM_OPT_POS_NK_S Position: component outside feed tol

(s) *

511085 FM_OPT_POS_NK_R Position: component outside feed tol

(r) *

SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual

CEID Name Description

511086 FM_OPT_POS_NK_C Position: component outside feed tol

511087 FM_OPT_POS_NK_L Position: component outside feed tol

(l) *

511088 FM_OPT_POS_NK_G Position: component outside feed tol

(g) *

511089 FM_OPT_POS_NK_B Position: component outside feed tol

(b) *

511090 FM_OPT_POS_NV_DEF Position: evaluation not possible*

511091 FM_OPT_POS_NV_S Position: evaluation not possible (s) *

511092 FM_OPT_POS_NV_R Position: evaluation not possible (r) *

511093 FM_OPT_POS_NV_C Position: evaluation not possible (c) *

511094 FM_OPT_POS_NV_L Position: evaluation not possible (l) *

511095 FM_OPT_POS_NV_G Position: evaluation not possible (g) *

511096 FM_OPT_POS_NV_B Position: evaluation not possible (b) *

511097 FM_OPT_POS_NR_DEF Position: no result*

511098 FM_OPT_POS_NR_S Position: no result (s) *

511099 FM_OPT_POS_NR_R Position: no result (r) *

511100 FM_OPT_POS_NR_C Position: no result (c) *

511101 FM_OPT_POS_NR_G Position: no result (g) *

511102 FM_OPT_POS_NR_L Position: no result (l) *

511103 FM_OPT_POS_NR_B Position: no result (b) *

511104 FM_OPT_DIM_NV_DEF Dimension: evaluation not possible*

511105 FM_OPT_DIM_NV_S Dimension: evaluation not possible

(s) *

511106 FM_OPT_DIM_NV_R Dimension: evaluation not possible

(r) *

511107 FM_OPT_DIM_NV_C Dimension: evaluation not possible

511108 FM_OPT_DIM_NV_L Dimension: evaluation not possible

(l) *

511109 FM_OPT_DIM_NV_G Dimension: evaluation not possible

(g) *

511110 FM_OPT_DIM_NV_B Dimension: evaluation not possible

(b) *

511111 FM_OPT_BEIN_NV_DEF No. of pins: evaluation not possible*

511112 FM_OPT_BEIN_NV_C No. of pins: evaluation not possible

511113 FM_OPT_BEIN_NV_L No. of pins: evaluation not possible

(l) *

511114 FM_OPT_REIH_NV_DEF Colinearity: evaluation not possible*

SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual

CEID Name Description

511115 FM_OPT_TEIL_NV_DEF Spacing: evaluation not possible*

511116 FM_OPT_REIH_NV_C Colinearity: evaluation not possible

511117 FM_OPT_REIH_NV_L Colinearity: evaluation not possible

(l) *

511118 FM_OPT_TEIL_NV_C Spacing: evaluation not possible (c) *

511119 FM_OPT_TEIL_NV_L Spacing: evaluation not possible (l) *

511120 FM_OPT_BEIN_NR_DEF No. of pins: no result*

511121 FM_OPT_BEIN_NR_C No. of pins: no result (c) *

511122 FM_OPT_BEIN_NR_L No. of pins: no result (l) *

511123 FM_OPT_DIM_NR_DEF Dimension: no result*

511124 FM_OPT_DIM_NR_S Dimension: no result (s) *

511125 FM_OPT_DIM_NR_R Dimension: no result (r) *

511126 FM_OPT_DIM_NR_C Dimension: no result (c) *

511127 FM_OPT_DIM_NR_L Dimension: no result (l) *

511128 FM_OPT_DIM_NR_G Dimension: no result (g) *

511129 FM_OPT_DIM_NR_B Dimension: no result (b) *

511130 FM_OPT_REIH_NR_DEF Colinearity: no result*

511131 FM_OPT_REIH_NR_C Colinearity: no result (c) *

511132 FM_OPT_REIH_NR_L Colinearity: no result (l) *

511133 FM_OPT_TEIL_NR_DEF Spacing: no result*

511134 FM_OPT_TEIL_NR_C Spacing: no result (c) *

511135 FM_OPT_TEIL_NR_L Spacing: no result (l) *

511136 FM_OPT_DIM_NK_DEF Dimension: component outside feed

tol. *

511137 FM_OPT_DIM_NK_S Dimension: component outside feed

tol. (s) *

511138 FM_OPT_DIM_NK_R Dimension: component outside feed

tol. (r) *

511139 FM_OPT_DIM_NK_C Dimension: component outside feed

tol. (c) *

511140 FM_OPT_DIM_NK_L Dimension: component outside feed

tol. (l) *

511141 FM_OPT_DIM_NK_G Dimension: component outside feed

tol. (g) *

511142 FM_OPT_DIM_NK_B Dimension: component outside feed

tol. (b) *

511143 FM_OPT_BEIN_NK_DEF No. of pins: component outside feed

tol. *

511144 FM_OPT_BEIN_NK_C No. of pins: cmpnt outside feed tol.
