SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 217 of 241
CEID Name Description
611078
FM_GUI_TEXT_F_HT2_TIMEOUT
Lifting table 2 timeout
611079 FM_GUI_TEXT_F_HT2_BERO1
Lifting table 2 Bero 1 defective
611080 FM_GUI_TEXT_F_HT2_BERO2
Lifting table 2 Bero 2 defective
611081 FM_GUI_TEXT_F_HT2_DREH
RICHT
Lifting table 2 incorrect direction of
rotation
611082 FM_GUI_TEXT_F_STOPPER2 Stopper at the back (processing area
2) defect
611083 FM_GUI_TEXT_F_ZENTR2 Error ceramic substrate centering 2
611084 FM_GUI_TEXT_F_LP_ZURUE
CK_BB2
Pull back PCB in second processing
conveyor
611085
FM_GUI_TEXT_F_LP_LANG_BB2
Overlength PCB second processing
conveyor
611086
FM_GUI_TEXT_F_LP_ENTNOMM
EN_BB2
PCB removed from processing
conveyor 2 in automatic mode
611087
FM_GUI_TEXT_F_UEBERN_AB
Error upon PCB transfer in output
conveyor
611088
FM_GUI_TEXT_F_UEBERG_AB
Error upon PCB transfer in output
conveyor
611089
FM_GUI_TEXT_F_LP_LANG_AB
Overlength PCB in output conveyor
611090 FM_GUI_TEXT_F_BRV_MIN Width adjustment at limit switch
minimum width
611091 FM_GUI_TEXT_F_BRV_MAX Width adjustment at limit switch
maximum width
611092 FM_GUI_TEXT_TSP_EF_LP_E
NTFERNEN
Conveyor already occupied (remove
PCB)
611093 FM_GUI_TEXT_TSP_EF_LP_EI
NLEGEN
Conveyor not occupied (load PCB)
611094 FM_GUI_TEXT_TSP_EF_LP_
WEITERE
Conveyor occupied by other PCBs
(remove PCBs)
611095 FM_GUI_TEXT_TSP System error from conveyor control
611096 FM_GUI_TEXT_TSPNOPRG System error: No program loaded
611097 FM_GUI_TEXT_TSPRAMNOK System error: Faulty RAM
611098 FM_GUI_TEXT_TSPCMDNOK System error: command unknown
611099 FM_GUI_TEXT_TSPBUSY System error: command is not being
accepted
611100 FM_GUI_TEXT_TSPPARFALS
E
System error: parameter value range
exceeded
611101
FM_GUI_TEXT_TSPLPNRFALSE
System error: unknown PCB no.
transmitted
611102 FM_GUI_TEXT_TSPLPWEITE
R
System error: PCB has already been
enabled
611103 FM_GUI_TEXT_TSPLPOPTION
SFALSE
System error: incorrect options for
PCB
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 218 of 241 ©Siemens AG, all rights reserved
CEID Name Description
611104 FM_GUI_TEXT_TSPNOLP System error: no PCB available
611105 FM_GUI_TEXT_TSPLPVORHA
NDEN
System error: PCB already exists
611106
FM_GUI_TEXT_TSPLPGEKLEMM
T
System error: PCB already clamped
611107
FM_GUI_TEXT_TSPNOTAUS
Emergency stop actuated
611108
FM_GUI_TEXT_TSPFLASHNOK
System error in Flash RAM
611109
FM_GUI_TEXT_
TSPLPAUSFAHREN
PCB not transported out of machine
611110 FM_GUI_TEXT_TSPNOINIT Conveyor not initialized
611111 FM_GUI_TEXT_TSPHUNKNO
WMESSAGE
System error: unknown acknowledge
from transport
611112 FM_GUI_TEXT_TSPHANSWE
RFORMAT
System error: synchr. feedback too
short
611113 FM_GUI_TEXT_TSPHCNV
BANDNR
System error: invalid conveyor
number
611114 FM_GUI_TEXT_TSPHSPUR
NUMMER
System error: unknown track number
611115 FM_GUI_TEXT_TSPBAND
UNBEKANNT
System error TSP: unknown conveyor
number received
611116 FM_GUI_TEXT_TSPHBREITE
MESSEN
Conveyor width could not be
measured
611117 FM_GUI_TEXT_TSPHBREITE
EINSTELLEN
Preset width could not be adjusted
611118 FM_GUI_TEXT_LPH_
ERRTSPFF
Fatal TSP error
* Depending on the collection event, some of the status variables <ERRORTYPE>,
<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,
<ERRORINFO1> and <ERRORINFO2> will be updated at each of these fiducials
collection events.
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 219 of 241
Matrix Tray Changer (MTC)
CEID Name Description
810011 MTCtrayChanged MTC Tray changed 41
810012 MTCtransPos MTC in transport position 41
810013 MTCrefillPos MTC in refill postion 41
810015 MTCrefRun MTC Reference Run 41
810020 MTCrefillFinished Refill finished 41
810021 MTCfillLevelChanged Filling level changed 41
810022 FM_MTC_CONFIG MTC configuration error
810023 FM_MTC_ERROR General MTC error
810024 FM_MTC_WARNING Warning: Temperature or load too
high
810025 FM_MTC_NOT_READY MTC is not ready for automatic mode
Barcode
CEID Name Description
RPT
920001 Bcread The barcode reader transmits a
barcode <BCININPUTCONVEYOR>
24
920002 ComponentBCread A component barcode is read via GUI
or by the Siplace Mobile Verifier.
In case of Siplace Mobile Verifier this
event may be repeated if a new setup
is active and the component barcodes
are still the same as before.
27
920011 BCTwinRead The barcode reader transmits a
barcode
<BCINTWININPUTCONVEYOR> from
the twin conveyor.
30
921006 FM_GK_LR_DURCHTRANSP Caution: PCB transported through by
line computer
GEM-Kernel
CEID Name Description
1000001 EqConstChange Equipment constant
changed at the machine
0
1000002 S10Ack 1
Communication Model
