SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 218 of 241 ©Siemens AG, all rights reserved
CEID Name Description
611104 FM_GUI_TEXT_TSPNOLP System error: no PCB available
611105 FM_GUI_TEXT_TSPLPVORHA
NDEN
System error: PCB already exists
611106
FM_GUI_TEXT_TSPLPGEKLEMM
T
System error: PCB already clamped
611107
FM_GUI_TEXT_TSPNOTAUS
Emergency stop actuated
611108
FM_GUI_TEXT_TSPFLASHNOK
System error in Flash RAM
611109
FM_GUI_TEXT_
TSPLPAUSFAHREN
PCB not transported out of machine
611110 FM_GUI_TEXT_TSPNOINIT Conveyor not initialized
611111 FM_GUI_TEXT_TSPHUNKNO
WMESSAGE
System error: unknown acknowledge
from transport
611112 FM_GUI_TEXT_TSPHANSWE
RFORMAT
System error: synchr. feedback too
short
611113 FM_GUI_TEXT_TSPHCNV
BANDNR
System error: invalid conveyor
number
611114 FM_GUI_TEXT_TSPHSPUR
NUMMER
System error: unknown track number
611115 FM_GUI_TEXT_TSPBAND
UNBEKANNT
System error TSP: unknown conveyor
number received
611116 FM_GUI_TEXT_TSPHBREITE
MESSEN
Conveyor width could not be
measured
611117 FM_GUI_TEXT_TSPHBREITE
EINSTELLEN
Preset width could not be adjusted
611118 FM_GUI_TEXT_LPH_
ERRTSPFF
Fatal TSP error
* Depending on the collection event, some of the status variables <ERRORTYPE>,
<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,
<ERRORINFO1> and <ERRORINFO2> will be updated at each of these fiducials
collection events.
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 219 of 241
Matrix Tray Changer (MTC)
CEID Name Description
810011 MTCtrayChanged MTC Tray changed 41
810012 MTCtransPos MTC in transport position 41
810013 MTCrefillPos MTC in refill postion 41
810015 MTCrefRun MTC Reference Run 41
810020 MTCrefillFinished Refill finished 41
810021 MTCfillLevelChanged Filling level changed 41
810022 FM_MTC_CONFIG MTC configuration error
810023 FM_MTC_ERROR General MTC error
810024 FM_MTC_WARNING Warning: Temperature or load too
high
810025 FM_MTC_NOT_READY MTC is not ready for automatic mode
Barcode
CEID Name Description
RPT
920001 Bcread The barcode reader transmits a
barcode <BCININPUTCONVEYOR>
24
920002 ComponentBCread A component barcode is read via GUI
or by the Siplace Mobile Verifier.
In case of Siplace Mobile Verifier this
event may be repeated if a new setup
is active and the component barcodes
are still the same as before.
27
920011 BCTwinRead The barcode reader transmits a
barcode
<BCINTWININPUTCONVEYOR> from
the twin conveyor.
30
921006 FM_GK_LR_DURCHTRANSP Caution: PCB transported through by
line computer
GEM-Kernel
CEID Name Description
1000001 EqConstChange Equipment constant
changed at the machine
0
1000002 S10Ack 1
Communication Model
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 220 of 241 ©Siemens AG, all rights reserved
CEID Name Description
Control State Model
1000003 GemControlStateLOCAL SIPLACE goes to local
mode
0
1000004 GemControlStateREMOTE SIPLCAE goes to remote
mode
0
1000005 GemEquipmentOFFLINE SIPLACE goes OFFLINE 0
1000018 ControlModeChanged <CONTROLMODE> state
changed (LCU, GEM-Host,
Stand-alone)
0
1000019 OperatorCommand The operator issued a „host
– available“ command
while the SIPLACE is in
Remote mode.
1
Spooling
1000007 GemSpoolingActivated Spooling is activated. This
event is never reported
directly to the host, but
instead is directed as the
first message to the spool
file
0
1000008 GemSpoolingDeactivated The spool area has been
completely emptied.
0
1000009 GemSpoolTransmitFailure Communication error
during transmitting spooled
messages to host. This
event is never reported
directly to the host, but
instead it is directed to the
end of the spool file
0
Process State Model
1000010 Init2Process The Siplace change its
processing state from
„Machine Initialization“ to
„Processing“
1
1000011 Process2Init The Siplace change its
processing state from
„Processing“ to „Machine
Initialization“
1
1000012 Process2SingleFunction The Siplace change its
processing state from
„Processing“ to „Single
Function“
1
1000013 SingleFunction2Process The Siplace change its
processing state from
„Single Function“ to
„Processing“
1
1000014 Init2SingleFunction The Siplace change its
processing state from
„Machine Initialization“ to
1
