SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 219 of 241
Matrix Tray Changer (MTC)
CEID Name Description
810011 MTCtrayChanged MTC Tray changed 41
810012 MTCtransPos MTC in transport position 41
810013 MTCrefillPos MTC in refill postion 41
810015 MTCrefRun MTC Reference Run 41
810020 MTCrefillFinished Refill finished 41
810021 MTCfillLevelChanged Filling level changed 41
810022 FM_MTC_CONFIG MTC configuration error
810023 FM_MTC_ERROR General MTC error
810024 FM_MTC_WARNING Warning: Temperature or load too
high
810025 FM_MTC_NOT_READY MTC is not ready for automatic mode
Barcode
CEID Name Description
RPT
920001 Bcread The barcode reader transmits a
barcode <BCININPUTCONVEYOR>
24
920002 ComponentBCread A component barcode is read via GUI
or by the Siplace Mobile Verifier.
In case of Siplace Mobile Verifier this
event may be repeated if a new setup
is active and the component barcodes
are still the same as before.
27
920011 BCTwinRead The barcode reader transmits a
barcode
<BCINTWININPUTCONVEYOR> from
the twin conveyor.
30
921006 FM_GK_LR_DURCHTRANSP Caution: PCB transported through by
line computer
GEM-Kernel
CEID Name Description
1000001 EqConstChange Equipment constant
changed at the machine
0
1000002 S10Ack 1
Communication Model
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 220 of 241 ©Siemens AG, all rights reserved
CEID Name Description
Control State Model
1000003 GemControlStateLOCAL SIPLACE goes to local
mode
0
1000004 GemControlStateREMOTE SIPLCAE goes to remote
mode
0
1000005 GemEquipmentOFFLINE SIPLACE goes OFFLINE 0
1000018 ControlModeChanged <CONTROLMODE> state
changed (LCU, GEM-Host,
Stand-alone)
0
1000019 OperatorCommand The operator issued a „host
– available“ command
while the SIPLACE is in
Remote mode.
1
Spooling
1000007 GemSpoolingActivated Spooling is activated. This
event is never reported
directly to the host, but
instead is directed as the
first message to the spool
file
0
1000008 GemSpoolingDeactivated The spool area has been
completely emptied.
0
1000009 GemSpoolTransmitFailure Communication error
during transmitting spooled
messages to host. This
event is never reported
directly to the host, but
instead it is directed to the
end of the spool file
0
Process State Model
1000010 Init2Process The Siplace change its
processing state from
„Machine Initialization“ to
„Processing“
1
1000011 Process2Init The Siplace change its
processing state from
„Processing“ to „Machine
Initialization“
1
1000012 Process2SingleFunction The Siplace change its
processing state from
„Processing“ to „Single
Function“
1
1000013 SingleFunction2Process The Siplace change its
processing state from
„Single Function“ to
„Processing“
1
1000014 Init2SingleFunction The Siplace change its
processing state from
„Machine Initialization“ to
1
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 221 of 241
CEID Name Description
„Single Function“
1000015 SingleFunction2Init The Siplace change its
processing state from
„Single Function“ to
„Machine Initialization“
1
1000020 Proc1PPChangeEvent Board with a new
processing program enters
Processing 1 Area
1
1000021 Proc2PPChangeEvent Board with a new
processing program enters
Processing 2 Area
1
Process Program Management
1000017 GemBadDownloadEvent Error in downloaded
program
1
1001018 FM_GEM_INIT GEM: Error upon
initialization of GEM
interface to host*
1001019 FM_GEM_INIT_MC GEM: Error upon
initialization of interface to
MC*
1001020 FM_GEM_INIT_GUI GEM: Error upon
initialization of interface to
user interface*
1001021 FM_GEM_SIPLACE GEM: Error in SIPLACE
GEM software*
1001022 FM_GEM_OP_MELDUNG GEM: Most recent operator
message could not be sent
to the host*
1001023 FM_GEM_VERB_GUI GEM: Faulty connection
between GEM interface
and user interface*
1001024 FM_GENERAL General Error Event
Error messages can be
reported either with specific
error events (an Error
Event with a CEID for each
individual error) or with the
General Error Event that
reports all errors.
The General Error Event
has an error code
<LASTERRORCODE>,
which contains the CEID of
the specific Error Event.
The SV <LASTFMTEXT>
which contains the error
text of the specific Error
Event is also available.
44
