SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 231 of 241
<SEGMENTINFO2 >,
<SEGMENTINFO3>
will be resetted.
2010024 PCBreadyProc2Conv1 Placement is finished for the PCB in the
conveyor 1 processing area 2.
1
2010025 PCBstartProc1Conv2 Start of the placement process for the
PCB in the conveyor 2 processing area 1
<GANTRYINFO1>, <GANTRYINFO4>,
<SEGMENTINFO1 >,
<SEGMENTINFO4>
will be resetted.
1
2010026 PCBreadyProc1Conv2 Placement is finished for the PCB in the
conveyor 2 processing area 1.
1
2010027 PCBstartProc2Conv2 Start of the placement process for the
PCB in the conveyor 2 processing area 2
<GANTRYINFO2>, <GANTRYINFO3>,
<SEGMENTINFO2 >,
<SEGMENTINFO3>
will be resetted.
1
2010028 PCBreadyProc2Conv2 Placement is finished for the PCB in the
conveyor 2 processing area 2.
1
2010029 PickPlaceStartProc1 The machine is starting to pick up and
place components in Processing1 Area.
1
2010030 PickPlaceStopProc1 The Pick/Place process in Processing 1
Area has been interrupted or is finished.
1
2010031 PickPlaceStartProc2 The machine is starting to pick up and
place components in Processing2 Area.
1
2010032 PickPlaceStopProc2 The Pick/Place process in Processing 2
Area has been interrupted or is finished.
1
2010034 TapeCut3 Tape cut at location 3 1
2010035 TapeCut4 Tape cut at location 4 1
Other Error-Events
CEID Name Description
2211001 FM_ABH_KEIN_BE Component not at nozzle after pick-
up
2211002 FM_BEST_KEIN_BE Component not at nozzle before
placement
2211003 FM_ABH_SPURLEER Track empty, no component during
pick-up
2211004 FM_FM_SPURLEER Flatpack magazine is empty
2211005 FM_MHS_CRASH_GEFAHR Second gantry in travel range
2211006 FM_VAK_DELTA_GRENZE_SP RV: intervals open - closed vacuum
values too low
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 232 of 241 ©Siemens AG, all rights reserved
CEID Name Description
2211007 FM_VAK_OFFEN_GRENZE_SP
RV: vacuum values for open
nozzles too high
2211008 FM_VAK_KUBISCH_SP RV: cubic vacuum values faulty
2211009 FM_VAK_NICHT_KUBISCH_SP RV: non-cubic vacuum values faulty
2211010 FM_VAK_FHL_NR_UNBEK_SP RV: unknown vacuum error number
2211011
FM_CAN_MSG_ABWERFEN_SP
RV: Defective motor for rejecting
2211012
FM_TW_SP_PINOLE_GEZOGEN
Caution: Sleeve in extended
position, do not move placement
head!
2211013 FM_VAK_SEGM_UNDICHT_SP Leak in RV-head segment after
placement
2211015 FM_BZ_SCHUETZ_SZ4 Software enable relay defective
2211016 FM_BZ_DRUCKTLUFT Compressed air failure for too long
2211017 FM_BZ_UNBEK_ZUST Status unknown
2211018 FM_BZ_SCHUTZ Cover not correct
2211019 FM_BZ_HALTEPUNKT Break point not defined
2211020 FM_BZ_SCHLUESSEL Unknown key-switch message
2211021 FM_BZ_SENDENBZ Unknown message code to BZ
2211022 FM_BZ_HAUPTSCHUETZ Hardware defect (relay)
2211023 FM_GUI_TEXT_BB_ERR_WAR
TE_ENDE_PORT_KPF_REF
Gantry and head reference run
failed
2211024 FM_GUI_TEXT_BB_ERR_WAR
TE_ENDE_HOEHE_REF
Height reference run failed
2211025 FM_GUI_TEXT_BB_ERR_FAHR
E_POSITION
Unable to move gantry
2211027
FM_GUI_TEXT_TI_FOERD_FOLIE
Error upon cover foil of a tape
feeder
2211028 FM_BETR_DATEN_NOK Error upon producing operating data
for a HOST system
2211029 FM_HEAD_TIMEOUT Timeout during head functions
2211031 FM_NOZZLE_NOK Nozzle cannot be changed, function
not executed
2211039 FM_GEM_SPOOL_FULL Spoolfile is nearly full, machine
stopped (only if safespoolmode is
activ)
2211040 FM_REMOTE_START Remote Start by Gem-Host
2211041 FM_REMOTE_STOP Remote Stop by Gem-Host
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 233 of 241
SIPLACE Placement Head 3
CEID Name Description
2310001 Place3Cycle Placement cycle completed on head 3 and
<PLACEINFO3> , <PLACEINFO3SUB1> will be
updated.
33
2310002 PickUp3Cycle Pick-up cycle completed on 3 and
<PICKUPINFO3> will be updated.
42
2310003 Nozzle3changed <NOZZLECONF3> changed on placement-head
3.
35
2310004 RefRunHead3 Head <HEIGHTHEAD3> reference run complete
on head 3.
37
2310005 NozzleRefRun3 <NOZZLECONF3> length reference run complete
on head 3.
35
2310006 VacRefRun3 <VAKUUMDATAHEAD3> reference run complete
on head 3.
39
SIPLACE Placement Head 4
CEID Name Description
2410001 Place4Cycle Placement cycle completed on head 4 and
<PLACEINFO4>, <PLACEINFO4SUB1> will be
updated.
33
2410002 PickUp4Cycle Pick-up cycle completed on head 4 and
<PICKUPINFO4> will be updated.
43
2410003 Nozzle4changed <NOZZLECONF4> changed on placement-head
4.
36
2410004 RefRunHead4 Head <HEIGHTHEAD4> reference run complete
on head 4.
38
2410005 NozzleRefRun4 <NOZZLECONF4> length reference run complete
on head 4.
36
2410006 VacRefRun4 <VAKUUMDATAHEAD4> reference run complete
on head 4.
40
Traceability (only available if Traceability-Option is installed)
CEID Name Description
2510001 TraceData Traceabilitydata for one PCB 46
2510002 SpliceDetected Splicedetection at a Feeder (only if splicedetction
sensor is installed)
47
2510003 TraceOn Traceability activ 01
2510004 TraceOff Traceability inactiv 01
