SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 38 of 241 ©Siemens AG, all rights reserved
3.3.1 SIPLACE Process State Transitions
# From Trigger To Description
1 Unknown Power-Up Machine
Initialization
At power-up, the
Equipment defaults to the
Machine initialization state.
2 Machine
Initialization
Machine is
ready
Processing All data is available to
produce a board. All
peripheral equipment like
the Vision system is
initialized and the machine
has finished the reference
runs correctly. In this state
the machine will start its
work, when a PCB is put on
the input conveyor
3 Processing new Data from
the Host
Machine
Initialization
New production data is sent
while the machine is
processing a board. The
board will be finished and
the machine will go to the
Machine initialization state
4 Machine
Initialization
a) Fatal Error
during machine
initialization
b) Stop-Button
on GUI
Single
Function
When a fatal error occurs
during machine
initialization it will
automatically switch to
single function mode.
In the case that the
operator presses the Stop-
Button on the GUI, the
machine will first end the
board in the center
conveyor (if there is one)
and will then enter the
single function mode.
5 Single
Function
Start-Button on
GUI
Machine
Initialization
When the machine is in
single function mode, the
operator press the Start-
button and the Prestate
was machine Initialization
the machine will return to
the Machine initialization
state.
6 Processing a) Fatal Error
during machine
initialization
b) Stop-Button
on GUI
Single
Function
When a fatal error occurs
during processing the
machine will automatically
switch to single function
mode.
In the case that the
operator press the Stop-
Button on the GUI, the
machine will first end the
board in the center
conveyor (if there is one)
and will then enter the
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 39 of 241
# From Trigger To Description
single function mode.
7 Single
Function
Start-Button on
GUI
Processing When the machine is in
single function mode, the
operator press the Start-
button and the Prestate
was Processing the
machine will return to the
Processing state.
3.3.2 SIPLACE Process States
{ XE Machine Initialization }Machine Initialization
In this state, the peripheral equipment is initialized and the reference run is executed.
Machine is waiting for a processing program or is preparing a new processing program
for production.
{ XE Processing }Processing
In this state, the SIPLACE is producing a board or is waiting for a board to produce.
{ XE Single function }Single function
In this state, the Operator can teach fiducials, react on run-time-errors like empty
feeders.
3.3.3 Intermediate States
In case of 3 State Transitions, an intermediate state will occur for briefly. This
intermediate state is required for internal reasons and is also reported:
State Transition 2 consists of
Init2Process è Process2Init è Init2Process (see A in the diagram)
State Transition 3 consists of
Process2Init è Init2Process è Process2Init (see B in the diagram)
State Transition 6 consists of
Process2Init è Init2SingleFunction (see C in the diagram)
3.3.4 Related Variables
The following table lists the variables (SV's, EC's, or DVVALS) which are relevant to the
Equipment processing states. For a more complete description of these variables, see
"Chapter 6 Variables".
Variable Name VID
{XE
„PREVIOUSPROCESSSTATE“}PREVIOUS
PROCESSSTATE
1002012
{XE „PROCESSSTATE“}PROCESSSTATE
1002011
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 40 of 241 ©Siemens AG, all rights reserved
3.3.5 Related Collection Events
The following lists the collection events (CEIDs) which are relevant to the Process State.
For a more complete description of these events, see "Appendix B -- Collection Events"
or the description in this chapter.
Collection Event CEID
{XE „Init2Process“}Init2Process
1000010
{ XE „Process2Init“ }Process2Init
1000011
{ XE Process2SingleFunction
}Process2SingleFunction
1000012
{ XE SingleFunction2Process
}SingleFunction2Process
1000013
{ XE Init2SingleFunction
}Init2SingleFunction
1000016
{ XE FunctionSingle2Init
}FunctionSingle2Init
1000017
