SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 50 of 241 ©Siemens AG, all rights reserved
3.6.2 Related Collection Events
There are CEID's related to then Material Movement Capability. For a more complete
listing of these collection events, please see "Appendix B -- Collection Events".
The Events with a '2' at the end of the Event name (e.g., PCBreachedOutputConveyor2)
refer to the 2
nd
belt of a dual conveyor.
Collection Event CEID HS50,
HF
S25
PCBreachedInputConveyor 610031
4 4
PCBreachedFirstProcessingConveyor 610061
4 4
PCBreachedIntermediateConveyor 610062
4
PCBreachedSecondProcessingConveyor 610063
4
PCBreachedOutputConveyor 610033
4 4
PCBreachedInputConveyor2 610034
4 4
PCBreachedFirstProcessingConveyor2 610066
4 4
PCBreachedIntermediateConveyor2 610067
4
PCBreachedSecondProcessingConveyor2 610068
4
PCBreachedOutputConveyor2 610036
4 4
TransportWidthMeasured 610037
4 4
TransportWidthMeasured2 610044
4 4
TakeOutInConv 610051
4 4
TakeOutProcessing1Conv 610069
4 4
TakeOutIntermediateConv 610070
4
TakeOutProcessing2Conv 610071
4
TakeOutOutConv 610052
4 4
TakeOutInConv2 610053
4 4
TakeOutProcessing1Conv2 610072
4 4
TakeOutIntermediateConv2 610073
4
TakeOutProcessing2Conv2 610074
4
TakeOutOutConv2 610054
4 4
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
©Siemens AG, all rights reserved page 51 of 241
3.7 Equipment Terminal Services
The SIPLACE supports exchange of free text messages with the Host (SECS Stream
10). This Equipment accepts the following messages from the Host, and responds
accordingly if the W-Bit is set to 1:
{XE "S10F3"}S10F3 /* {XE "Single Line Data"}Single Line Data */
{XE "S10F5"}S10F5 /* {XE "Multi Line Data"}Multi-Line Data */
{XE "S10F9"}S10F9 /* {XE "Broadcast"}Broadcast */
The message text will be displayed on the Equipment's CRT. Collection Event {XE
"HostMsgAck"}S10Ack (CEID 1000002) occurs once the operator has acknowledged the
message and an Event Report will be sent to the Host (if enabled).
The S10F3 and S10F9 are restricted to a single TEXT data item, but S10F5 can contain
multiple TEXT data items. Each TEXT data item is limited to 160 characters. Each data
item in S10F5 will be displayed on a separate line at the equipment.
If the Operator has not acknowledged an existing message when the Host sends another
message, the new message will be displayed and the old one discarded.
The Host can send a message with a 0-length text to clear the Operator text display.
Also, the Equipment allows the operator to send a single block message to the Host via
S10F1. The maximum length of this text is 160 characters. The S10F2 response from
the Host is ignored.
3.7.1 Related Variables
There are no relevant variable for the Equipment Terminal Capability.
3.7.2 Related Collection Events
There is one CEID related to the Equipment Terminal Capability. For a more complete
listing of these collection events, please see "Appendix B -- Collection Events".
Collection Event CEID
{XE „HostMsgAck“}HostMsgAckr
1000002
SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual
Page 52 of 241 ©Siemens AG, all rights reserved
3.8 Error Messages
The SIPLACE provides standard Stream 9 messages to report SECS-II errors. See 4.9
"SECS Message Detail" for detailed description of these messages:
{XE "S9F1"}S9F1 {XE "Unrecognized Device ID"}Unrecognized Device ID
{XE "S9F3"}S9F3 { XE "Unrecognized Stream"}Unrecognized Stream
{XE "S9F5"}S9F5 { XE "Unrecognized Function"}Unrecognized Function
{XE "S9F7"}S9F7 { XE "Invalid Data"}Invalid Data
{XE "S9F9"}S9F9 { XE "Transaction Timeout "}Transaction Timeout
{XE "S9F11"}S9F11 {XE "Data Too Long"}Data Too Long
3.8.1 Related Variables
There are no Variables relevant for Error Messages.
3.8.2 Related Collection Events
There are no CEID related to Error Messages.
