SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual

3.7 Equipment Terminal Services

The SIPLACE supports exchange of free text messages with the Host (SECS Stream

10). This Equipment accepts the following messages from the Host, and responds

accordingly if the W-Bit is set to 1:

{XE "S10F3"}S10F3 /* {XE "Single Line Data"}Single Line Data */

{XE "S10F5"}S10F5 /* {XE "Multi Line Data"}Multi-Line Data */

{XE "S10F9"}S10F9 /* {XE "Broadcast"}Broadcast */

The message text will be displayed on the Equipment's CRT. Collection Event {XE

"HostMsgAck"}S10Ack (CEID 1000002) occurs once the operator has acknowledged the

message and an Event Report will be sent to the Host (if enabled).

The S10F3 and S10F9 are restricted to a single TEXT data item, but S10F5 can contain

multiple TEXT data items. Each TEXT data item is limited to 160 characters. Each data

item in S10F5 will be displayed on a separate line at the equipment.

If the Operator has not acknowledged an existing message when the Host sends another

message, the new message will be displayed and the old one discarded.

The Host can send a message with a 0-length text to clear the Operator text display.

Also, the Equipment allows the operator to send a single block message to the Host via

S10F1. The maximum length of this text is 160 characters. The S10F2 response from

the Host is ignored.

3.7.1 Related Variables

There are no relevant variable for the Equipment Terminal Capability.

3.7.2 Related Collection Events

There is one CEID related to the Equipment Terminal Capability. For a more complete

listing of these collection events, please see "Appendix B -- Collection Events".

Collection Event CEID

{XE „HostMsgAck“}HostMsgAckr

1000002

SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual

3.8 Error Messages

The SIPLACE provides standard Stream 9 messages to report SECS-II errors. See 4.9

"SECS Message Detail" for detailed description of these messages:

{XE "S9F1"}S9F1 {XE "Unrecognized Device ID"}Unrecognized Device ID

{XE "S9F3"}S9F3 { XE "Unrecognized Stream"}Unrecognized Stream

{XE "S9F5"}S9F5 { XE "Unrecognized Function"}Unrecognized Function

{XE "S9F7"}S9F7 { XE "Invalid Data"}Invalid Data

{XE "S9F9"}S9F9 { XE "Transaction Timeout "}Transaction Timeout

{XE "S9F11"}S9F11 {XE "Data Too Long"}Data Too Long

3.8.1 Related Variables

There are no Variables relevant for Error Messages.

3.8.2 Related Collection Events

There are no CEID related to Error Messages.

SIPLACE GEM SW Version GEM 505.03 SP1 HOST Interface Manual

3.9 Clock

The SIPLACE contains Clock/Calendar hardware, by which it knows the current date and

time.

The Host can send {XE "S2F31"}S2F31 to set the Equipment's Clock/Calendar

hardware.

The Host can send {XE "S2F17"}S2F17 to read the Equipment's Clock/Calendar

hardware.

The Operator can initiate a Date/Time request from the Host. The Equipment will send

S2F17 to the Host and will set its clock according to the data in the S2F18 reply.

3.9.1 Related Variables

The following table lists the variables (SV's, EC's, or DVVALS) which are relevant to

material movement. For a more complete description of these variables, see "Appendix

A -- Variables".

Variable Name VID

{XE „CLOCK“}CLOCK

1002022

{XE „TIME“}TIME

1002023

3.9.2 Related Collection Events

There are no CEID related to the Clock Capability.
