FX-3R Maintenance Guide
11-5
5) Adjust the volume (only the feeder float sensor).
Adjust the volume after the sensor mounting height, mounting position in the Y-direction
(sensor is secured to the center of the oval hole in the sensor bracket), and light-axis have
been adjusted.
Volume
Slotted precision
screwdriver
Figure 11-7 Adjusting the Sensitivity of the Feeder Float Sensor
<Units and tools to be used for adjustment>
• NF12 (NF16 or NF24 is also accepted.) → Non-lock type
• NF16N (NF12N or NF24N is also accepted.)
∗ The above units are used for adjustment of the feeder float sensor on the transport side.
• NF16 (NF12, NF24, NF12N, NF16N, or NF24N is also accepted.)
• NF32 feeder (NF323S, NF324S, or NF32FS is also accepted.)
• Bulk feeder (BF10, BF11, or BF12 is also accepted.)
∗ The above units are used for adjustment of the feeder float sensor outside the machine.
• Phillips screwdriver and slotted precision screwdriver
Rev. 1.00
FX-3R Maintenance Guide
11-6
c Adjusting the feeder float sensor on the transport side
1) Turn the volume on the light emission side counterclockwise to the minimum position to put the
sensor in the shut-down state.
2) Gradually turn the volume clockwise toward the maximum position and stop turning when both
the red and green lamps on the light receiving side are lit.
3) Set the NF12 at the left, center, and right positions of the bank. Open and close the front cover
to check that the sensor is turned OFF.
Front cover
NF12 feeder
NF16N feeder
Figure 11-8 Adjusting the Feeder Float Sensor
Move the sensor back
and forth.
Light
receiving
(Transport side)
Light
emission
Figure 11-9 Adjusting the Feeder Float Sensor
∗ If the sensor is not turned OFF even though the font cover is opened, the sensor mounting
position may deviate in the Y-direction. If this occurs, loosen the sensor mounting screws and
move the sensor back and forth.
4) If the sensor mounting position is changed in work step 3), adjust the light axis and perform the
adjustment again from step 1).
(The above adjustments are absolutely necessary since the volume adjustment amount is
changed as the sensor position is moved.)
5) Put the NF16N in the same manner as described for step 3) to check that the sensor is turned
OFF.
∗ If the sensor is not turned OFF even though the font cover is opened, the sensor mounting
position may deviate in the Y-direction. If this occurs, loosen the sensor mounting screws and
move the sensor back and forth. (Normally, move the sensor toward the transport side.)
6) If the sensor mounting position is changed in work step 5), adjust the light axis and perform the
adjustment again from step 1).
(The above adjustments are absolutely necessary since the volume adjustment amount is
changed or the sensor is not turned ON or OFF correctly with NF12 as the sensor position is
moved.)
Rev. 1.00
FX-3R Maintenance Guide
11-7
Rev. 1.00
7) Check that a shielding object with a height of 35.6 mm from the bank support and bank
connection surface does not turn ON the sensor and that a shielding object with a height of
36.0 mm turns ON the sensor.
∗ If a shielding object with a height of 35.6 mm turns ON the sensor, remove the FSD spacer
(E2157729000) and insert the shim. Conversely, if a shielding object with a height of 36.0 mm
does not turn ON the sensor, insert the shim. (At this time, pay special attention so that the
position in the Y direction does not deviate.) After the shim has been inserted, check the height
again and make the adjustment again from step 1).
