3.8 ELECTRICAL WIRING
Up [V] = POWER VOLTAGE
Uc [V] = CONTROL VOLTAGE
ELMC
3
4
1
2
L
1
L
2
L
3
N
L
Up(V) = 1x200 - 230Vac (50-60Hz)
Electrical isolator +
Protection
Up(V)
Up(V) = 3x200 - 230Vac (50-60Hz)
ELMC
3
4
1
2
L
1
L
2
L
3
N
L
Electrical isolator +
Protection
Up(V)
ELMC
3
4
1
2
L
1
L
2
L
3
N
L
Up(V) = 3x380 - 690Vac (50-60Hz)
Uc (V) = 1x200 - 230Vac (50-60Hz)
Uc(V)
Up(V)
Electrical isolator
+
Protection
Up(V) = 3x380 - 420Vac (50-60Hz)
with neutral
ELMC
3
4
1
2
L
1
L
2
L
3
N
L
Up(V) + Neutral
Electrical isolator
+
Protection
ELECTROVAP® ELMC
24
Up(V) = 3x380–690Vac (50-60Hz)
OPTION : Transformer : sec : 2x115V
ELMC
3
4
1
2
L
1
L
2
L
3
N
L
Up(V)
Electrical
isolator
+
Protection
OPTION
Transfo.
100 VA
sec
prim
F
ELECTROVAP® ELMC
25
3.8.1 Remote information board
The contact can be changed to NO or NC by wiring according to the following diagrams (e.g. wiring on 30 & 31 = NO
contact).
3.8.2 RS485 – Hardware connection
RS485 connection must be plugged on the J2 connector:
• Terminal 1: Data -
• Terminal 2: Data +
• Terminal 3: GND
The SW1 switch is used to turn line resistance on or off. Depending on your
needs, these resistances can be activated or deactivated (see diagram).
X22 Connector (36-37-38): Remote
steam production dry contact.
X21 Connector (33-34-35): Remote
general fault dry contact.
X20 Connector (30-31-32): Remote tank
maintenance dry contact.
1
2
3
4
3
2
1
J2
SW1
On
Off
K4A
X10
Main board
SW1–2
J2
1 : Data –
2 : Data +
3 : GND
+5V
680
SW1–3
120
SW1–1
680
Main board
Ref : 500102
X18
Ref 500400
500400
X23
X20
X22
X21
X2
0
30 31 32
X2
1
33 34 35
X2
2
36 37 38
NO
NC
NC
NC
NO
NO
Fig. B 3-8.
Fig. A 3-8.
