ELECTROVAP® ELMC
35
4 COMMISSIONING
Before operation, please check that your installation complies with the
manufacturer's technical recommendations. Check all power cables electrical
connections. Remove the blocking blue foam ring from the tank.
Marker 1: Validation & change menu button
Marker 2: Upward button
Marker 3: Downward button
Marker 4: Manual drain button for maintenance
Marker 5: LED = Steam production indication
• Open the main water supply valve.
• Switch on the main power supply (power and control voltages).
• Switch on the unit switch.
• If the unit asks you for a commissioning code, note the serial number on the
nameplate and contact your agent to obtain this code.
• Enter your three-digit code by doing this:
Press one of the keys 1, 2, 3 and the display will show you 0XX, with the flashing zero to eventually change it by
pressing 2 or 3.
Once arrived at your digit, validate it by pressing key 1 and your second digit flashes. Repeat the previous two
operations to show the last two digits.
Very important: do not forget to validate the last digit.
• Enter water quality in the displayed menu.
• The device is ready to respond any production request.
• During steam production, the LED (5) lights up.
5
1
2
3
4
Fig. 4 Humidifier display
ELECTROVAP® ELMC
36
5 SYSTEM MANAGEMENT
5.1 USER INFORMATION MENU (READ ONLY)
Any press on the enter key from any of
these menus
MENU: HUMIDIFIER
CONFIGURATION
WWW.DEVATEC.COM/
ELECTROVAP / V3-35
ACTUAL CONTROL SIGNAL
Y XX %
ACTUAL CONTROL SIGNAL
Y XX. Xuu
CHECK RH SENSOR
Y XX %
SET POINT -- % Hr
HR MEASURE - - %
If in digital control
Uu- mA or V depending on the
regulation
If HR < 7%
If in an HR probe
MENU: HUMIDIFIER
STATUS
STEAM HUMIDIFIER
ELMC 10 3x400V
STEAM PRODUCED
XX.Xkg XX.XKG/h
ACTUAL CURRENT
Xx. X A
ELECTROVAP® ELMC
37
WATER TEMP. IN
CYLINDER XX°C
TEMP.(°C) SENSOR
NOT CONNECTED
If function enabled
If the temperature exceeds 105 °C
STEAM DEMAND
XX%
STEAM DEMAND
NO DEMAND
Check
SAFETY SWITCH
SAFETY SWITCH
(1-2) OPEN
Standard functioning
If demand is zero
If safety switch open & steam
demand on
If in an HR probe
NO DEMAND
MODBUS STOP
If the stop is prompted by the
Modbus
DRAINING AFTER
XX H STOP
PRODUCT BEFORE CLEAN
XXX KG
NEXT SERVICE
DUE XXXH
HOUR METER
XX H
STEAM METER
XX KG
