ELECTROVA P ® E LMC 37 W A TER TEMP . IN CYLINDER XX°C TEMP .(°C) SENSOR NO T CONNECTED If funct ion enabled If the t em perature exceeds 10 5 °C STE AM DEMAND XX% STE AM DEMAND NO DEMAND Check SAFETY SWIT CH SAFETY SWIT…
ELECTROVAP® ELMC
36
5 SYSTEM MANAGEMENT
5.1 USER INFORMATION MENU (READ ONLY)
Any press on the enter key from any of
these menus
MENU: HUMIDIFIER
CONFIGURATION
WWW.DEVATEC.COM/
ELECTROVAP / V3-35
ACTUAL CONTROL SIGNAL
Y XX %
ACTUAL CONTROL SIGNAL
Y XX. Xuu
CHECK RH SENSOR
Y XX %
SET POINT -- % Hr
HR MEASURE - - %
If in digital control
Uu- mA or V depending on the
regulation
If HR < 7%
If in an HR probe
MENU: HUMIDIFIER
STATUS
STEAM HUMIDIFIER
ELMC 10 3x400V
STEAM PRODUCED
XX.Xkg XX.XKG/h
ACTUAL CURRENT
Xx. X A
ELECTROVAP® ELMC
37
WATER TEMP. IN
CYLINDER XX°C
TEMP.(°C) SENSOR
NOT CONNECTED
If function enabled
If the temperature exceeds 105 °C
STEAM DEMAND
XX%
STEAM DEMAND
NO DEMAND
Check
SAFETY SWITCH
SAFETY SWITCH
(1-2) OPEN
Standard functioning
If demand is zero
If safety switch open & steam
demand on
If in an HR probe
NO DEMAND
MODBUS STOP
If the stop is prompted by the
Modbus
DRAINING AFTER
XX H STOP
PRODUCT BEFORE CLEAN
XXX KG
NEXT SERVICE
DUE XXXH
HOUR METER
XX H
STEAM METER
XX KG
ELECTROVAP® ELMC
38
CONCENTRATION IN
PROGRESS: WAIT
MINERAL
CONCENTRATED
If high level detected
If high level undetected
ELECTRICAL POWER
Xx. X KW
BACK TO THE
BEGINNING
