ELECTROVAP® ELMC
42
CYLINDER SELECT
XXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXX
XXXXX
IDENTIFICATION
OF ELMC XX
VALUE: CLEANABLE(EV), CLEANABLE (EA), CLEANABLE
(ED).
EV: Tap water, EA: softened water, ED: demineralized
water
VALUE between 1 and 32: Identifies humidification when
it is connected to a communication bus
PROTOCOL
NETWORK
SPEED DATA
XXXXb/s
VALUE: MODBUS RTU 8-N-1, MODBUS RTU 8-N-2,
BACNET MS/TP
VALUE: 1200/2400/4800/9600 b/s: Syncs the speed of
communication between the ELMC and the
communication system
SETTING TEMP
WATER 65°C: XXX
VALUE: YES or NO: Allows to activate the function of
keeping water temperature at 65°C when the device is
stopped.
WARNING this option requires additional accessories
DRAINING AFTER
SHUT DOWN? Xxx
Value: YES or NO
DRAINING AFTER Xxx
HRS
Value: between 1 and 168 hours
If the end-of-season drain is active
BACK TO THE BEGINNING
ELECTROVAP® ELMC
43
5.4 MAINTENANCE ALERTS
M4: CONTACTOR TO
REPLACE
After 10,000 hours of operation, it is recommended to
replace the contactor. The unit is not stopped
M3: MAINTENANCE
NOT DONE: PURGE
This message appears if 100 hours elapsed between the
appearance of the M2 and M3 message and no
maintenance has been done.
Then the unit is shut down and follows the procedure:
1. 1. Emptying the cylinder
2. 2. Cooling the cylinder
3. 3. Ready for maintenance
M2: MAINTENANCE
TO DO
The maintenance timer has arrived at 0, it is necessary to
do the maintenance of the device. The unit is not stopped
M1: 50 HOURS
CONTROL
This message will appear 50 Hrs after the first start.
It is then necessary to check the correct tightening of
electrical and hydraulic connections (steam pipe, drain
system, water supply...). The unit is not stopped
TO CARRY OUT A RESET FOR THE ABOVE
MESSAGES, FOLLOW THIS PROCEDURE:
-Switch the unit to drain by pressing the manual drain button (4).
-Press button 3 for at least 5 seconds.
5
1
2
3
4
ELECTROVAP® ELMC
44
5.5 DEFAULT MESSAGE
Meaning:
The signal passing through the contactor is OFF when it should be ON. The contactor no longer works and there is no
steam production.
In this case:
When this message appears, the cylinder is drained, the general fault contact is activated, and the unit is then stopped.
Causes and remedies:
1. Check the F1 (2A) fuse on the main map.
2. Check the connection of the connector wires of the contactor
3. Make sure the X01 (wire 12 and 13) is well connected to the map
4. Change the faulty contactor
Meaning:
The signal passing through the contactor is ON when it should be OFF. The contactor has a defect and produces steam
when it should not.
CAUTION : switch the humidifier off before any handling
In this case:
When this message appears, the cylinder is drained, the general fault contact is activated, and the unit is then stopped.
Causes and remedies:
1. Turn off the device
2. Check the condition of the contactors visually
3. Make sure the X01 (wire 12 and 13) is well connected to the main board
4. Change the faulty contactor
Meaning:
The water inlet valve is defective, the high level is not reached after 20 minutes.
In this case:
When this message appears, the cylinder is drained, the general fault contact is activated, and the device is not
stopped.
Causes and remedies:
1. Make sure the water supply faucet is open
2. Check for water in the cylinder
3. Change the water inlet valve
Alarm
P1
INFORMATION "CONTACTOR COIL FAILURE"
Alarm
P2
INFORMATION "CONTACTOR BLOCKED"
Alarm
P3
INFORMATION "WATER INLET VALVE"
