ELECTROVAP® ELMC
45
Meaning:
The water supplement of the cylinder is not done properly
In this case:
When this message appears, the cylinder is drained, the general fault contact is activated, and the device is not
stopped.
Causes and remedies:
1. Check water supply. The pressure must be constant and between 2 and 8 bar. If in doubt, install a pressure
regulator set at 2 bar on the supply pipe. Also check the condition of the water inlet valve, the electrical connection
and the condition of fuse F2 (2A). Change the valve and fuse if defective.
2. Blue hose inside the filling cup incorrectly positioned or pinched. Replace the
hose as shown in the picture.
3. Check for proper condensate drainage. Must absolutely be drained, otherwise it will accumulate in the steam
hose, creating water projections and pressure rise in the tank, preventing the unit from being filled.
4. Verify that the bleed valve is properly closed. A piece of scale can block the valve closure and cause a leak,
preventing proper filling of the unit.
5. Electronic issue. Replace the main board and check that there is no steam or water flow in the electrical
compartment.
Meaning: Draining is not done properly
In this case:
When this message appears, the cylinder is drained, the general fault contact is activated, and the device is not
stopped.
Causes and remedies:
1. Check the condition of the F3 fuse, if defective, change it.
2. Clean the draining circuit, in case a piece of limestone blocks.
3. Check how the coil valve works, if defective, change it.
Information "SEE DRAIN CIRCUIT"
Alarm
P4
INFORMATION "NO INLET WATER"
Alarm
P5
Blue hose
ELECTROVAP® ELMC
46
Meaning: Draining is not properly done
In this case:
When this message appears, the cylinder is drained, the general fault contact is activated, and the device is stopped.
Causes and remedies:
1. The drain system is clogged. Press the manual drain button, and check for the proper flow of water. Then clean
the inside of the cylinder. Check if there is limestone in the valve.
Alarm
P8
Information "CLEAN CYLINDER + DRAIN VALVE"
TO CARRY OUT A RESET FOR THE ABOVE
MESSAGES, FOLLOW THIS PROCEDURE:
-Switch the unit to drain by pressing the manual drain button (4).
-Press button 3 for at least 5 seconds.
5
1
2
3
4
ELECTROVAP® ELMC
47
6 MAINTENANCE
6.1 GENERAL INFORMATION
Periodic checks
• After an hour of operation, check for no water leaks in the middle and foot of the cylinder.
• After 50 hours of operation, check the condition of the cylinder. Make sure no arcing or flicker occurs between
the electrodes during operation.
Check the filter inside the water inlet valve as well as the drain system.
Please re-examine all the power cable connection terminals, as well as the clamps of the various pipes (steam,
drain, inside the wet part).
WARNING! Tighten the clamps when the cylinder is cold.
• After a year of operation, please check the condition of your steam hose, water drain and the internal pipes of the
unit. If some pipes seem damaged, it is essential to change them. Please tighten all connection terminals.
Warnings
After a prolonged use or with the use of high TH water, may be solid deposits on the electrodes which can increase
the concentration of water.
If electrical arcs appear inside the cylinder, your humidifier works under abnormal conditions and these arcs can cause:
• A significant heat increase that could overheat the plastic and even melt it, causing a hole and then a leak into the
unit.
• A disjunction of the device due to a high intensity created by the electrical arcs.
• Premature deterioration of heating electrodes.
• Burning of electrodes power cables.
In case of electric arcs
Check any points in case electrical arcs appear inside the cylinder:
• If your water is running with softened water, make sure your softener does not release salt into the appliance's
water supply pipes.
• Make sure the drain valve is working properly and maintain it.
• Check F3 drain valve fuse on the main board.
The humidifier has powered electrical components and the cylinder has heated elements.
Therefore, all work must be carried out by qualified and competent personnel.
Before working on the cylinder, make sure that the humidifier is switched off.
