11 Error M essages on M an ual Cont rol Operat ions Error code Message E316001 Memory allocation error E316002 Shared memory open error E316011 There is no input character E316012 Input character has irregularities E3160…

Q302004 Error has occurred during nozzle installation. Move to parking position?

Q302005 Extend shuttle?

Q302006 Do you interrupt automatic measurement?

Q302007 A nozzle is fixed to %s. Do you want to auto-return the nozzle?

Q302008 Extend MTS mark?

Q302009 Vacuum Calibration has been set already. (ATC No:%s) Would you like to disable the

setting?

Q302010 An error occurred during Auto. measuring nozzles. Would you like to discontinue the Auto.

measuring on the left station?

Q302011 An error occurred while installing nozzles. Would you like to move to the parking position?

[Error occurs] ? [Error No.] ? ?[ Error Info.] ???

Q302012 Move Z axis to where nozzles are taken off. Is that OK?

Q302013 Return Z axis to Laser height position. Is that OK?

Q302014 Please check if the backup plate is lifted up enough. It may be a little hard to see pins

when the plate is not lifted up. | Would you like to continue?

Q302015 There may be some units with ON state. Would you like to initialize these units?

I303000 Return to home of %s

I303001 Nozzle is removed from %s to ATC

I304000 Set online for MTC

I304001 Remove the nozzle from %s

I304002 A nozzle of %s is removed and return to %s of ATC

I304003 Set online for MTS

I304004 Please close the door of MTS

Error Messages on Manual Control Operations

Error code Message

E316001 Memory allocation error

E316002 Shared memory open error

E316011 There is no input character

E316012 Input character has irregularities

E316013 Input value exceeds predetermined data range

E316021 Return to home has not yet been completed

E316022 Servo is in the free state

E316031 Selected device is not install. Please reselect other device on HOD

W316041 There is no ATC that is allocated with nozzle. Allocate nozzle to ATC when setting up the

machine

W316042 Nozzle is not set on head

E316051 Z axis limit has been exceeded

E316101 Error has occurred when setting laser parameters code:%ld

E316102 Error has occurred during laser measurement(ONCE) code:%ld

E316103 Error has occurred during laser measurement(SWEEP) code:%ld

E316104 Error has occurred during the nozzle presence check | code:%ld

E316105 Error has occurred during the image data obtain. code:%ld

E316106 Error has occurred during the edge check data learning. code:%ld

E316107 Data has not been learned

E316301 MTC power off

E316302 MTC offline

E316303 MTC is in the supply state

E316401 MTS power off

E316402 MTS offline

E316403 MTS cannot move because of cover opening

E316404 The door of MTS opens

E316405 There is no specified stacker with the tray steps number

E316501 Error has occurred on axis code:%ld

E316502 The initialization error of transportation occurred. Return to home is interrupted. Error

code:%ld

E316503 The PWB was detected in the transportation road

Q317001 Exit manual control. Reset I/O?

Q317011 Return to home has not yet been completed. Return to home?

Q317021 Cannot return component. Trash component?

Q317031 Do you interrupt process?

Q317041 Is the tray of MTS stored?

I318001 Remove the component from %s

I318011 Set online for MTC

I318021 Set online for MTS

I318022 Please close the door of MTS

I318023 Remove the PWB on Conveyor

Error Messages on Idle Mode Operations

Error code Message

E397001 Memory allocation error

E397002 Shared memory open error

E397011 Return to home has not yet been completed

E397012 Servo is in the free state
