Error Messages on Setting of the Safe Direction of Each I/O Device

Error code Message

E399101 Memory allocation error

E399102 Shared memory open error

W399111 Return to home has not yet been completed

W399112 Servo is in the free state

Q399201 Do you continue reset I/O?

Q399211 cannot return component of %s. Trash component?

I399301 Remove the component from %s

I399311 Set online for MTC

I399312 Set online for MTS

Error Messages on a Production Program/Production

Error code Message

E500001 Window create error(%s

E500002 There is no memory enough <%s>

E500003 File reading error

E500004 The file can not be displayed <Err No : ?>

E500100 Incorrect character has been input

E500101 Input range has been exceeded. The resumption position of a placement point is set outside

of the possible range

E500102

“Input range has been exceeded. (Input range: %ld - %ld)”

E500200 PWB data has not been completed

E500201 Placement data has not been completed

E500202 Component data has not been completed

E500203 Pick-up data has not been completed

E500204 Mark data has not been completed

E500205 Vision data has not been completed

E500206 Teaching of acknowledgment of BOC mark has not been completed

E500207 Teaching of acknowledgment of IC mark has not been completed

E500208 The production program breaks

E500210 Auto. Select exists in the Pick data. Production can not be executed

E500211 There is no data which placement is specified

E500212 There is no pick point on both left and right sides in Fully Synchronized mode

E500213 The program can not be produced in the <%s> Production mode

E500214 Reference error from the Pick data to the Component data

E500215 In the accumulative mode, the number of PWBs to be produced is the same as that of

produced PWBs. Production can not be executed

E500220 Device enable of setup does not match pick data

E500300 Origin retrieval has not yet been completed

E500301 Servo is turned OFF

E500302 Air was down

E500303 Detected %s feeder float

E500401 Input order Simple Opt. Error <%s>

E500500 Teaching can not be executed

E500501 The selected device can not be used

E500502 With the selected device, it is impossible to move to the aimed position

E500503 Standard Pin position illegal. Correct coordinates can not acquire

E500605 An error occurred when disposing a component

E500700 An error occurred while Auto. PWB Width Alignment Control. The process gets discontinued

E500701 Para error. PWB Width Alignment Control occurred

E500800 A PWB is detected within the conveyors of both stations. Please remove the PWB

E500801 A PWB is detected within the conveyor of the Left station. Please remove the PWB

E500802 A PWB is detected within the conveyor of the Right station. Please remove the PWB

E501999 Abnormal stop <%s>

E500900 The connection with HLC is on-line. The production is not available with the currently selected

production program created by the machine

E500901 It is not connected to HLC. The production is not available with the currently selected

production program created by HLC

E500902 Online switch is not effective to the Setup data though the connection with HLC is turning on

E501000 MTC Move Failed

E501010 MTC Power is Off. Please Power On

E501011 MTC Emergency Switch is Pressed. Please Release the Switch

E501012 MTC is No Original

E501013 MTC is Off-Line Condition. Please change to On-Line

E501014 MTC is Door Open Condition. Please Close Cover

E501015 MTC is Cover Open Condition. Please Close Cover

E501016 MTC is Error Condition

E501017 MTC is Change Component Condition. Please Release the Change Condition

E501018 Component exists on the MTC Shuttle. Please Remove Component from Shuttle

E501019 Because MTC is Change Component Condition, home position return cannot be done. Please

Release the Change condition

E501100 MTS power off

E501101 MTS offline

E501102 MTS cannot move because of cover opening

E501103 The door of MTS opens

E501200 Communication error of DTS occurred

E501201 DTS status got an error. The process can not be performed

E501202 DTS’ cover is open. Please close the cover

E501203 DTS is not in the executable status. Would you like to have DTS return to Home position?

E501204 DTS is not in the executable status. Would you like to have DTS return to Home Position?

E501205 DTS is in the supplying status. Please release DTS from the status

E501300 No tracing data

E501400 [Vision] Memory access error

E501401 [Vision] Failed to collect System condition data

E501402 [Vision] Failed to collect Mark recognition condition data

E501403 [Vision] Failed to collect Component recognition condition data

E501404 [Vision] Failed to transmit System condition data to the Vision board

E501405 [Vision] Failed to transmit Bankmark recognition condition data to the Vision board

E501406 [Vision] Failed to transmit BOC mark recognition condition data to the Vision board

E501407 [Vision] Failed to transmit IC mark recognition condition data to the Vision board

E501408 [Vision] Failed to transmit Component recognition condition data to the Vision board

E501409 [Vision] Data index error exceeds the specified range

E501410 [Vision] Unknown request (Program error)

E503001 Retry List message file (RETRYLIST.MSG) cannot be opened

E503100 You try to set remain less than level now, OK?

E503200 It is not Program made by setting non-stop. A normal operation is not occasionally done when

producing as it is. Production start forcibly?

E503300 %s feeder bank is in lower position

E503301 MTC is in motion. Please wait for stop

E503302 Cover open

E503400 The sequence(%s) you selected is different from the one(%s) of when the production got

suspended illegally last time. Would you like to resume the production?

E503401 The Production start No. that is currently set(%s) is larger than the one(Left:%s Right:%s) of

when the production got suspended illegally last time. Would you like to start the production

though the PWB may become incomplete?

E503402 The Production stop No. that is currently set (%s) us smaller than the one (Left:%s Right:%s) of

when the production got suspended illegally last time. Would you like to start the production

though the PWB may become incomplete?

E503500 No completion change plan. Please use Feeder Bank

E506100 You can resume the production from the last suspended position |%s|%s| Would you like to

resume the production?

E506101 You need to delete the file if you do not resume the production from the last illegally suspended

position. |%s|%s| Would you like to delete the file?

E506102 Would you like to resume the production? The last suspended position |%s|%s
