36
Error Messages on Safety
Error code Message
E691001 Input/Output buffer status of CCL-48M does not get ready
E691002 Writing-in buffer of flush memory does not get useable
E691003 Deleting cue of flush memory does not get useable
E691004 WSM(Write State Machine) of flush memory does not get ready
E691005 Write-in voltage range error occurred in flush memory control
E691006 Write-in error occurred in flush memory control
E691007 Write-in error occurred in flush memory control
E691008 Command sequence error occurred in flush memory control
E691009 Lock Bit Set error occurred n flush memory control
E691010 Lock Bit Clear error occurred in flush memory control
E691011 The check word for the common data of flush memory is abnormal
E691012 The checksum for the common data of flush memory is abnormal
E691013 The data version for the common data of flush memory is abnormal
E691014 The data length for the common data of flush memory is abnormal
E691015 The data kind for the common data is abnormal
37
Error Messages on Self-calibration
Error code Message
E906001 Memory allocation error
E906002 Shared memory open error
E906011 The measured value exceeds the limit. Check the MS parameters set.
E906021 The machine has not zeroed yet.
E906022 The machine is in the servo free state.
E906031 The selected device is not installed on the machine. Re-select another device.
E906041 There is no available head.
E906042 There is no available VCS.
E906043
%s is disable. Selected unit can not measure
E906051 The No. 501 nozzle and 502 nozzles are not assigned to the ATC. Assign the nozzles to
the ATC on the ATC nozzle setup menu which is invoked from the Machine Setup menu.
E906052 The No. 508 nozzle and 507 nozzles are not assigned to the ATC. Assign the nozzles to
the ATC on the ATC nozzle setup menu which is invoked from the Machine Setup menu.
E906061 The machine could not recognize a mark of the calibration jig used for laser alignment.
Check the jig position.
E906062 The machine could not recognize a mark of the calibration jig used for laser alignment.
E906071 The machine could not pick up the calibration jig used for laser alignment. Check to see if
the jig is placed on the calibration block.
E906072 The machine could not pick up the calibration jig used for laser alignment. Check to see if
the jig is placed on the jig station.
E906073 The offset from the jig placement position to the calibration block position exceeds the limit.
Check the MS parameter.
E906074 The position of the calibration jig for used for laser alignment is abnormal. Check the jig
position.
E906075
Calibration jig for VCS has not been picked up. Check that jig is placed on jig station
E906101 An error occurred when the machine detected the height of the laser measurement surface.
E906102 An error occurred during setting of the laser parameter.
E906103 An error occurred during laser measurement (ONCE).
E906104 An error occurred during laser measurement (SWEEP).
E906105 An error occurred when the machine checked to see if there was a component.
E906201 An error occurred at the axis.
E906301
Error has occurred on axis code:%ld
Q907001 Will you set the safe direction of each I/O device ?
Q907002 The machine will terminate self-calibration. Save the settings?
Q907011 The machine has not zeroed yet. Zero the machine?
Q907021 A component cannot be returned. Discard the component?
I908001 Remove a component at ?.
I909001 The No. ? nozzle will be removed.
I909002 The ? will be returned to the jig station.
38
B. CORRECTIVE ACTIONS
E100010 “Failed to initialize the Windows Socket”
[Cause] A critical error occurred while initializing the system.
[Treatment] Please turn on the power supply of the machine after finishing everything and
shutting down the machine
If the error occurs even after the rebooting, there is a possibility that a system file
is broken.
Please take a note of the error number and contact our technical service dept. for
information.
E100020 “Failed to initialize OLE. Confirm the OLE Library version”
[Cause] An error occurred while starting the axis control process.
[Treatment] Please turn on the power supply of the machine after finishing everything and
shutting down the machine
If the error occurs even after the rebooting, there is a possibility that a system file
is broken.
Please take a note of the error number and contact our technical service dept. for
information.
E102010 “Fatal system error occurred. Abort the process”
[Cause] A critical error occurred while initializing the system.
[Treatment] Please turn on the power supply of the machine after finishing everything and
shutting down the machine.
If the error occurs even after the rebooting, there is a possibility that a system file
is broken.
Please take a note of the error number and contact our technical service dept. for
information.
E102020 “You tried to start up, before the end of the previous system
program. Exit the system program, and start again”
[Cause] The next main process got started before the main process fully completed.
[Treatment] Please turn on the power supply of the machine after finishing everything and
shutting down the machine.
If the error occurs even after the rebooting, there is a possibility that a system file
is broken.
Please take a note of the error number and contact our technical service dept. for
information.
E102100 “There was a fatal failure while starting the KE-2000 system.
Avoiding the possible damages, the system is going to abort the
process. (error code = %d)”
[Cause] A critical error occurred during the initialization.
The details of the error during the initialization are shown and the system is shut
down.
? : Detailed error code (Hexadecimal display)
0
∼
3F
：
Failure count in creating flags to manage events
40
：
Failure count in initializing IPC for internal communication
100
：
MC starting error.
101
：
MC starting procedure 1 error
