091 The component length error occurs.
− The system picked up the wrong component.
− The setting of the allowable range is inappropriate.
− The system recognized the detected straight line
incorrectly.
092 The component width error occurs.
− The system picked up the wrong component.
− The setting of the allowable range is inappropriate.
− The system recognized the detected straight line
incorrectly.
093 The component length/width error occurs.
− The system picked up the wrong component.
− The setting of the allowable range is inappropriate.
− The system recognized the detected straight line
incorrectly.
010 The component size error occurs.
− The component aspect ratio is less than 1.2 (the
longer side to the shorter side).
102 The gravity detection error occurs.
− The system picked up the wrong component.
(The specified component dimensions indicate that
the shape of a component is a rectangle, but the
detected shape is a square.)
103 The system did not detect the inclination of a
component correctly when recognizing its gravity.
− The system picked up the wrong component.
− The specified component placement angle is wrong.
999 Other errors
− The hardware malfunctions.
RES 1 1 0FC 0 5 **052
Description of the error: When the system detects a side and corner of an
outline-recognized component whose ID is “0”, it found that the angle of two straight lines
exceeds the allowable range.
Example
268
9. Detailed Explanation of the Recognition Errors of General-Purpose Vision
Components (Lead Components/Outline-Recognized Components)
‘RES M N MLT_LEAD Index ErrCode …..’
M: Number of components recognized at the same time
N: Phase number for simultaneous component recognition
Index: Component identification number
Err
Code
Description of an error Assumed cause
1 ELGNum Pos Bend A lead is bent.
2 ELGNum Num There are too few leads on a
component.
3 ELGNum Pos There is a lead whose length is
abnormal.
4 ELGNum The system did not detect any lead on a
component.
5 ELGNum Num There are only a few leads on a
component.
6 ELGNum Num There are too many leads on a
component.
7 ELGNum The lead pitch is abnormal.
− The causes of the errors described other
than “ELGNum” are the same as those for a
standard lead component.
8 12 0 The system failed to position a
component.
− The setting of the lead assignment is wrong.
− The entered lead width/length is wrong.
− The hardware malfunctions.
8 12 0 RC1 504
RC2
The system failed to detect any lead.
− This error occurs due to a wrong component
type.
− This error occurs also when a component is
not picked up.
− This error occurs also when a lead(s) is
(are) not displayed clearly due to its (their)
stains or oxidation.
− This error occurs also when the light does
not turn on.
− This error occurs also when contrast
between a lead and its background is low.
− This error occurs also when there are many
leads and many marks or substances
similar with a lead on a component.
8 12 0 RC21 508
RC2
The system failed to position a
component.
− The lead assignment setting is not correct.
− A wrong lead width/length is entered.
− This error occurs also when a lead(s) is
(are) not displayed clearly due to its (their)
stains or oxidation.
− This error occurs also when contrast
between a lead and its background is low.
− This error occurs when there are many
leads and marks or other substances
similar with a lead on a component.
− The actual lead length is shorter than the
specified length.
− This error occurs when the lead corner is
too round.
8 12 0 RC21 510
RC2
Time-out error (It takes four seconds or
more for the system to recognize a
component, and the system interrupts
recognition of the component. This
error occurs at the VCS whose version is
1.11AF or later.)
− The lead assignment setting is not correct.
− A wrong lead width/length is entered.
− This error occurs also when a lead(s) is
(are) not displayed clearly due to its (their)
stains or oxidation.
− This error occurs also when 8contrast
between a lead and its background is low.
− This error occurs when there are many
leads and marks or substances similar with
a lead on a component.
8 12 5 ELGNum
Pos
The system failed to detect a certain
lead of a lead group.
− The entered lead pitch, lead width or lead
length is wrong.
− This error occurs when there is a substance
similar with a mark around a lead.
− This error occurs also when the system has
not performed calibration (setting of the
pixel rate).
269
8 13 0 The system failed to position a
component with the division recognition
function.
− The lead assignment setting is not
correct.
− A wrong lead width/length is entered.
− This error occurs also when a lead(s) is
(are) not displayed clearly due to its
(their) stains or oxidation.
− This error occurs also when the light
does not turn on.
− This error occurs also when contrast
between a lead and its background is
low.
− This error occurs when there are many
leads and marks or other substances
similar with a lead on a component.
8 13 0 RC1 504
RC2
The system failed to position a
component with the division recognition
function.
− The lead assignment setting is not
correct.
− This error occurs when the system does
not pick up a component.
− This error occurs also when a lead(s) is
(are) hardly displayed due to its (their)
stains or oxidation.
− This error occurs also when the light
does not turn on.
− This error occurs also when contrast
between a lead and its background is
low.
− This error occurs when there are many
leads and marks or other substances
similar with a lead on a component.
8 13 0 RC1 508
RC2
The system failed to detect a lead with
the division recognition function.
− The lead assignment setting is not
correct.
− A wrong lead width/length is entered.
− This error occurs also when a lead(s) is
(are) not displayed clearly due to its
(their) stains or oxidation.
− This error occurs also when contrast
between a lead and its background is
low.
− This error occurs when there are many
leads and marks or other substances
similar with a lead on a component.
− This error occurs also when the lead
corner is too round.
8 13 0 RC1 510
RC2
A time-out error is caused with the
division recognition function. (It takes
four seconds or more for the system to
recognize a component, and the system
interrupts recognition of the component.
This error occurs at the VCS whose
version is 1.11AF or later.)
− The lead assignment setting is not
correct.
− A wrong lead width/length is entered.
− This error occurs also when a lead(s) is
(are) not displayed clearly due to its
(their) stains or oxidation.
− This error occurs also when contrast
between a lead and its background is
low.
− This error occurs when there are leads
and marks or substances similar with a
lead on a component.
8 13 5 ELGNum
Pos
The system failed to detect a certain
lead of a lead group with the division
recognition function.
− The entered lead pitch, lead width or lead
length is wrong.
− This error occurs when there is a mark or
substance similar with a lead around a
lead.
− This error occurs also when the system
has not performed calibration (setting of
the pixel rate)
8 14 ELGNum Err1 The system could not detect any mark
on a component.
− This error occurs when the system
recognizes a mark at a place where no
mark should be located.
− This error occurs also when the light
does not turn on.
− This error occurs also when a mark is in
contact with the mark detecting area.
− This error occurs also when a mark is
stained very much.
− This error occurs also when the VCS
hardware malfunctions.
− This error occurs also when the picked
component position is shifted from the
regulated position greatly.
