1 − 6
(3) Laser height
− Laser measurement height (in laser centering method)
The figure below indicates the measurement position when the laser centering
method is selected. The distance between the nozzle tip to the measurement
position which is radiated with a laser beam is called “laser height”. The laser height
is specified in the component data.
Figure 1.1.2.5 Definition of Laser Height
− Default Laser height
Default laser heights are set for some component types and heights. Table 1.1.2.5
shows the relation between component heights and default laser heights.
Table 1.1.2.5 Component Types and Default Laser Heights
Component type Measurement position Laser height (mm)
Square chip
t
-
2
MELF
t
-
2
Aluminum
electrolytic
capacitor
- (t –)
= 0.45
GaAsFET
-0.5
(To be continued)
Nozzle
Laser height
Laser beam
Nozzle
Component
Component
height
Measurement
p
osition with laser
Component height
Measurement
p
osition with laser
Component height
Measurement
p
osition with laser
Measurement
p
osition with laser
Component height
1 − 7
Component type Measurement position Laser height (mm)
SOT
-
= 0.25
SOP
HSOP
-0.7t
SOJ
-0.65t
QFP
-0.7
t
QFJ (PLCC)
-0.65
t
PQFP (BQFP)
-0.45t
TSOP
-0.7t
TSOP 2
-0.7t
(To be continued)
Component height
Measurement
p
osition with laser
Molding
Component height
Measurement
p
osition with laser
Molding
Component height
Molding
Component height
Measurement
p
osition with laser
Molding
Component height
Measurement position
with laser
Molding
Component height
Measurement
position with laser
Molding
Measurement
p
osition with laser
Component height
Molding
Measurement position
with laser
Measurement position
with laser
Molding
Component height
1 − 8
Component type Measurement position Laser height (mm)
BGA
FBGA
-0.86t
Network resistor
Same as that of the
square chip
Trimmer
- (t – 0.7)
Unidirectional
lead connector
2-way lead
connector Z-lead
connector
-1.0
J-lead socket
0
Gull-wing socket
0
Socket with
bumper
0
Other
components
-0.5t
Measurement
position with
laser
Component height
Molding
Component height
Measurement position
with laser
Measurement position
with laser
Component height
Measurement position
with laser
Component height
-0.5t
t
Component height
Component height
Component height
Measurement
position with
laser
Measurement
position with
laser
Measurement
position with
laser
Component height
Measurement
position with laser
Molding
