4 – 203
3) <OK> button (F8 key)
This button validates the result of measurement, then saves the obtained
values into Component data. The “Measurement” dialog box reappears.
4) <CANCEL> button (ESC key)
This button cancels the result of measurement, then the previous
“Measurement” dialog box reappears.
5) <RETRY> button (F10 key)
This button measures the current component under the same conditions
again.
6) Short-cut keys
On the “Result of measurement” dialog box, the following short-cut keys are
provided.
Keyboard
key
Operation
panel key
HOD key Operation
F8 ENTER Validates the result.
F10 Re-measures the current component.
ESC CANCEL Returns to the previous screen.
4.12.2.4.3 Continuous measurement
• When you select the [All component] command on the menu, the “Continuation
measurement” dialog box appears on the screen.
• On the “Continuation measurement” dialog box, set the measurement items and
range.
• When you click the <MEAS.> button or press the <START> switch on the
“Continuation measurement” dialog box, the system measures components within
the range you specified, and displays the “Result of continuation measurement”
dialog box every time it finishes measuring one component.
• When you click the <OK> button, the result of measurement is saved into
Component data. The system repeats this operation until it finishes measuring the
last component within the range specified, then returns to the “Continuation
measurement” dialog box.
• If you click the <STOP> button (or ESC key) or if the system detects an error during
measurement, the system enters Single Measurement mode.
4 – 204
(1) Setting on the Continuation measurement dialog box
When you select the [All component] command on the menu, the following
“Continuation measurement” dialog box appears on the screen.
Figure 4.12.2.4.3.1 Continuation measurement dialog box
1) Component of meas. (Component of measurement)
Set the item(s) displayed here if you want to measure only components which
satisfy the certain requirements of Component data.
① All compo. (All components)
Measures all components specified in Component data.
② Thin compo. (Thin components)
Measures only components whose height is specified in the edit box or
lower.
③ Appointed compo. type (Appointed component type)
Measures only components whose type is specified in the combo box.
4 – 205
④ Appointed nozzle No.
Measures only components which require a nozzle selected in the combo
box.
⑤ Laser centering compo. (Laser centering components)
Measures only components which are to be centered with laser.
⑥ Vision centering compo. (Vision centering components)
Measures only components which are to be centered with the VCS (not
available to a KE-2030/KE-2010).
2) Bounds of meas. (Bounds of measurement)
Check this check box to specify the component number to further select
components among those which already satisfy the conditions specified with
the “Component of meas.” items. When you check this check box, you can
specify the following items.
① Start compo. No. (Start component No.)
Check this check box to specify the component data number of the first
component to be measured.
Check this box, then change the first component number displayed in the
edit box.
② End compo. No. (End component No.)
Check this check box to specify the component data number of the last
component to be measured.
Check this box, then change the last component number displayed in the
edit box.
③ Only placement compo. (Only placement components)
Check this check box if only components specified in Placement data are
to be measured.
